US$120,000.00-210,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Type
Centerless Grinding Machine
Controlling Mode
Artificial
Cylindrical Grinder Type
End Cylindrical Grinder
Certification
CE, ISO 9001
Grinding Wheel
P500*400*305mm
Transport Package
Wooden Case
Specification
3500*1850*1720mm
Packaging & Delivery
Package Size
360.00cm * 200.00cm * 190.00cm
Package Gross Weight
10000.000kg
Product Description
M11100 Wide Wheel Centerless Grinding machine
1. Salient features:
1.1.Grinding wheel and Regulating wheel
1.1.1.The wide grinding wheel can increase the grinding allowance in a single pass, and decrease repeating, to raise efficiency.
1.1.2.The grinder designed for double moving wheels, while grinding bracket fixed. The frame of regulating wheel moves for adjustment and workpiece fixed in order to equipped different feed devices.
1.1.3.The spindles of grinding wheel and regulating wheel adopted five-plate short bearing bushed static-hydrodynamical oil film bearing, which with better rigidity,and meet the need of heavy loading grinding and precise grinding.
1.1.4.The grinding wheel equipped hydrostatic guideway, moves sensitively(feed slightly), and antiseismic to avoid wearing.
1.2.Electric
1.2.1.AC frequency converter is used for regulating wheel speed control .
1.2.2.Hydraulic transmission & stepless speed regulation are adopted on regulating wheel & grinding wheel dresser.
1.3.Cooling
1.3.1.The coolant system is equipped with magnetic coolant separator.
1.4. Machine body and design
1.4.1. Equipped automatic plunge device in the grinder.
1.4.2. Iron casting with high rigidity, natural aging.
2. Technical Data
| | |
| In-feed Grinding | Dia. | 10-100mm |
| | Length | 390mm |
| Through grinding | Dia. | 10-100mm |
| GW SPEC. (O.D.*width*I.D.) | P500*400*305mm |
| RW SPEC.(O.D.*width*I.D.) | PSA350*400*127mm |
| GW Speed | 1330r/min |
| RW Speed (stepless) | 10-200r/min |
Swiveling Angle of RW | Vertical | -2°~ +4° |
| | Horizontal | -2°~ +4° |
| GW min feeding amount | 0.002mm |
| GW dresser min feeding amount | 0.01mm |
| Height from center line of GW & RW to work rest | 290mm |
| GW Motor | 22kw |
| RW Motor | 2.2 kw |
| Power Supply | 3N 50HZ 380V |
| Dimension(L*W*H) | 3500*1850*1720mm |
| Machine Weight | About 10000kg |
Accuracy (stand bars) | Roundness | 0.002mm |
| | Cylindricity | 0.005mm |
| | Roughness | Ra.0.32μm |
>>
