5-20mm Supercritical Foaming Technology TPU PU Foam Sheet Board Extrusion Machine

US$50,000.00-200,000.00 1 Set (MOQ)

Basic Info.

Model NO.
AF-650
Type
Sheet Extruder
Plastic Processed
TPU EVA
Product Type
Extrusion Molding Machine
Feeding Mode
One Feed
Assembly Structure
Integral Type Extruder
Screw
Single-Screw
Engagement System
Full Intermeshing
Screw Channel Structure
Deep Screw
Exhaust
Don′t Exhaust
Automation
Automatic
Computerized
Computerized
Machine Color
Blue
Machine Certificate
CE
Application
Shoes Material
Inverter
ABB
Transport Package
Wood Package
Specification
AF-300, AF-650
Trademark
YAOAN (ANFU)
Origin
Dongguan
HS Code
8477209000
Production Capacity
100-200kg/Hr

Product Description

5-20mm Supercritical Foaming Technology TPU PU Foam Sheet Board Extrusion Machine For Shoe Material
Application:
This kind of machine is designed and manufactured by taking the advanced technology from home and abroad. It can be widely used in industries such as transportation, sports equipment, ships, aerospace, furniture, decorations, toys, protective equipment, and packaging
Main Characteristics:
Supercritical Foam Molding Technology M-TPU is microcellular TPU foam, produced using thermoplastic polyurethane (TPU) as the composition with clean supercritical carbon dioxide as blowing agent to form a large number of microcells in the matrix. Supercritical foam molding technology is a kind of physical foam molding technology, but also a kind of microcellular foam molding technology After the completion of this process, there will be no residue of formamide, odorless and non-toxic, and there is long-term protection for consumers and producers.
There is no cross-linking agent used in the production process, and it can be melted and recycled Supercritical foam materials used in automotive interior, rail transit and other fields, has its unique advantages:
1) No VOC, no odor, completely solve the odor problem;
2) Lightweight, density can be as low as 30Kg/m3, can reduce the weight of the whole vehicle;
3) Light weight, high strength, comprehensive mechanical properties are better than traditional foam materials;
4) Non-crosslinked, recyclable;
5) Excellent thermal insulation, shock absorption, waterproof, sound insulation performance.
Supercritical foam molding technology has been widely used in shoe materials, the process has gradually become the "black technology" force in the field of shoe materials, slowly pushed to the market, the application of supercritical foam process TPU shoe material return rate of up to 99%, is really the king of Kings!
Technical parameter:
Model AF-300 AF-650
Sheet Width 300mm 650mm
Sheet thickness 1.5-5mm 3-20mm
Screw diameter 45mm 120mm
Main motor power 15kw 75kw
Max. yield 30kg/h 250kg/h
Total power 20kw 80kw
Overall diameter 5*2*1.8m 12*3*2m
