Basic Info.
Certification
ISO 9001:2000, ISO 9001:2008, CE
Suitable for
Copper, Aluminum, Alloy, Carbon Steel, Stainless Steel
Control System
3D Graphical Delem Da66t CNC
CNC Control Axis
Y1-Y2-X-R-Z1-Z2-Axis & Crowning
Main Motor
Siemens From Germany Brand
Tubing Connector
Emb Form Germany Brand
Hydraulic System
Bosch-Rexroth Form Germany
Servo Motor/ Servo Drive
Yaskawa From Japan Brand
Product Name
CNC Press Brake Machine
Transport Package
Wooden Cases for CNC Press Brake
Specification
3900*1780*2710mm
Production Capacity
30 Set/Month
Product Description
Accurl Euro PRO B Series CNC Press Brake Bending Machine
Product Description
ACCURL CNC PRESS BRAKE EURO PRO SERIES
ACCURL design innovations are based on years of experience and have resulted in Smart-Fab series Press Brakes which allow for faster bending, and a better return and back gauge. Accurl Press Brakes will allow you to mass produce precision parts effectively and decrease your cost per part.
CNC CONTROL SYSTEM CNC BACKGAUGE
ACCURL press brake are provided are equipped with a backgauge constituted by a solid structure in order to assure the best repetitiveness and high precision in axes positioning. LAZERSAFE OPTICAL SAFETY GUARDS
Performance without compromise. ACCURLuse LazerSafe LZS-LG-HS guarding system offers a highly effective solution for both operator safety and machine productivi- ty.Designed for use with Lazer Safe's PCSS A Serice, the Lazersafe is category 4 compliant and meets the world's most demanding international safety standards(CE Certified Category 4 Safety Controller with integrated). ACCURL QUICK CLAMP SYSTEM
• safe and fast tool change
• substantial improvement in time consumption and related costs
• Secure against tool falling down
• Available in manual, pneumatic and hydraulic models.
• Mounting: Simply from the bottom into the housing, tighten-DONE!
• Easy to mount on your press brake.Modify cation of the press brake is not necessar Specification for CNC Press Brake
| Model(SMART FAB) | B1560 | B2580 | B32110 | B32135 | B32175 | B40175 | B32220 |
| Bending force | KN | 600 | 800 | 1100 | 1350 | 1750 | 1750 | 2200 |
| Bending Length | mm | 1500 | 2500 | 3200 | 3200 | 3200 | 4200 | 3200 |
| Between Columns | mm | 1100 | 2060 | 2700 | 2700 | 2700 | 3700 | 2700 |
| Daylight | mm | 405 | 405 | 430 | 430 | 430 | 430 | 430 |
| Slide Stroke | mm | 200 | 200 | 200 | 200 | 200 | 200 | 200 |
| Throat Depth | mm | 370 | 400 | 400 | 400 | 400 | 400 | 400 |
| Bolster Width | mm | 80 | 80 | 100 | 100 | 100 | 100 | 140 |
| Down Speed | mm/min | 200 | 200 | 180 | 180 | 160 | 160 | 160 |
| Pressing Speed | mm/min | 8 | 8 | 10 | 10 | 10 | 10 | 10 |
| Return Speed | mm/min | 180 | 180 | 150 | 150 | 150 | 150 | 140 |
| Back Gauge Stroke | mm | 500 | 600 | 800 | 800 | 800 | 800 | 800 |
| Outline Size | L | mm | 1825 | 2825 | 3500 | 3550 | 3500 | 4500 | 3500 |
| W | mm | 1650 | 1650 | 1650 | 1650 | 1650 | 1650 | 1730 |
| H | mm | 2300 | 2350 | 2650 | 2700 | 2700 | 2750 | 2900 |
| Weight | kg | 4600 | 5600 | 8000 | 9500 | 10000 | 12000 | 13200 |
