Vacuum Membrane Press Machine

Product Description

Vacuum membrane press machine
This type vacuum membrane press machine can be used to paste PVC film on furniture, cabinet door, speakers, relief doors, decoration panels for walls and other abnormal decoration shapes. With a special silicon sheet, it can also work with hot transfer film and wood veneer.
Technical parameters

Dimension(L*W*H)		9900*1950*1700mm
Work table size		2560*1300*60mm *2pcs
vacuum pump		63m³/h *2pcs
Air holder		4pcs
MAX.vacuum pressure		-0.1mpa(63m³/h)
Total power		28KW
Vacuum motor power		2.2KW
Operating power		7.8kw
Weight		3000kg
Control way		Touch screen
Minimum Order Quantity		1 set
Heating way		Metal tube heating,reheating by aluminum plate
PVC cutting		Pneumatic pvc cutting

1. This type vacuum membrane press machne workbench surface is made of high strength steel plate which is secondary hardening treatment and non-deformation until 200ºC in an hour.
2. There are 2 vacuum pumps and 4 gas holders can vacuumize quickly,the maximum ultimate vacuum is -0.1 mpa.
3. The heating pipes are metal in good quality,reheating by aluminum plate,surrounded by auxiliary heating,evenly, there is not orange peel lines, bubble, etc.in the surface, and heating box uses the sole insulation technology, thermal insulation and prevent accidental burns.
4.This vacuum membrane press machine is widely used in cabinet doors, wardrobe,wood composite door etc, can also be used to lamiante sliding door with soft package or wooden veneer , especially for hot stamping and heat transfer processing.
5.This vacuum membrane press machine with Automatic pneumatic cutting system,pneumatic locking system,double air passage ,PLC control
Detail photo of Vacuum Membrane Press Machine
Pneumatic pvc cutting
Final product from Vacuum Membrane Press Machine
This kind of vacuum membrane press machine is the best choice for produce kitchen cabinet door,wood door.
Our factory
Qingdao Qili Machinery CO.,LTD has more than 12 years experience for produce Woodworking Machine (Paper and PVC laminating Machine, PUR Laminating Machine, Profile Wrapping Machine, CNC router and vacuum membrane press machine.)Our company makes great efforts in the design, development and manufacture of cover adorn machines for many years, and we have accumulated rich experience in products' research and development. We never stop to advance and pursuit best.The convenient economical design and durable subassemblies help customers use facility easily. We are ready to introduce advanced technology into our new products. For each machine, we really concern about its function and practicability. We believe a good reputation roots from strong quality guarantee. Only with best durable, reliable and credible quality merchandise could win customers' heart, and our present leading position in cover adorn machine field results from it.
After sale service of Vacuum Membrane Press Machine:
One-year warrant for factory defeat,6 months warranty for electric components,we will change new parts under warranty free of charge,hower we don't take responsibilities for parts due to natural wear-out and operation by mistic or any misuses.We promise a whole-life after-sale maintenance and support,call us any time.
Note:Oversea customer may need to undertake the roundway tickets,provide acommodation and food for our after-sale stuff if need our stuff flies over,if not need we can only support you by email,videos,camera,ect.

---
