Lifting Bin Blender for Powder and Granule Materials

Product Description

APPLICATION
HGD Series Square Cone Mixer is used in pharm-aceutical industry mainly for mixing of guanules and powder, It gains the merits of large batch size proportional load supporting steady operation, etc. Meanwhile, it can be widely used in such areas as raw medicinematerial industry, chemical industry, foodstuff industry, etc.
FEATURES
a.There is no dead angle, no concave-convex face on surface. All angles are cambered The surface outside and inside is polished to high quality. Roughness of inner surface is less than 0.4μm. It's easy to wash.
b.Applying sealing ring on the cover to gain good airproof effect.
c.Fabricated butterfly valve having safety facility against wrong operation.
d.Loading coefficient is up to 80% with adjustable mixing time and speed.
e.The mixing uniformity can reach 99%.
f.It's in conformity with the GMP requirements.
The main technical parameters

Model	Main structural dimensions							Volume L	Net Load kg	Speed rpm	Machine Weight T	Total power kw
	L	W1	W2	H1	H2	H3	DN
HGD-400	2100	1450	1150	800	1900	2250	150	400	200	3-20	0.6	1.5
HGD-500	2250	1605	1250	800	2065	2405	150	500	250	3-20	0.7	2.2
HGD-600	2350	1700	1250	800	2120	2500	200	600	300	3-20	0.9	2.2
HGD-800	2500	1825	1250	800	2230	2625	200	800	400	3-20	1	3
HGD-1000	2750	1900	1250	800	2300	2700	200	1000	500	3-15	1.1	3
HGD-1200	2880	1950	1400	800	2430	2750	200	1200	600	3-15	1.2	4
HGD-1500	3000	2000	1400	800	2540	2800	250	1500	750	3-15	1.3	4
HGD-2000	3200	2350	1400	800	2680	3150	250	2000	1000	3-15	1.7	5.5
HGD-2500	3400	2500	1600	800	2840	3300	250	2500	1250	3-12	1.9	5.5
HGD-3000	3750	3050	1600	800	3000	3850	250	3000	1500	3-12	2.4	7.5
HGD-4000	3850	2875	1800	1000	3300	3875	250	4000	2000	2-10	2.9	7.5
HGD-5000	4200	3000	2000	1000	3430	4000	250	5000	2500	2-10	3.5	11
HGD-6000	4500	3300	2400	1000	3600	4300	250	6000	3000	2-10	4.8	11
HGD-8000	4900	3380	2600	1000	3900	4380	250	8000	4000	2-8	5.8	15
HGD-10000	5300	4300	2600	1000	4350	5300	250	10000	5000	2-8	6.9	15

Company Show
Company introduction: Jiangsu Xingxing Drying Equipment Co., Ltd.
Jiangsu Xingxing Drying Equipment Co.,Ltd has established in 1998 and it covers an area of 15000 square meters, possesses fixed asset of USD 7 million. The products have exported to US, Singapore, India, Ukraine, Russia, Korea and so on. The company have advanced production equipment , excellent technical team and after-sales service.
CERTIFICATE
Package:wooden case
Service:
pre-sale service
We Invite customers to visit our company and communicate on technical requirements face to face.
sale service
Responsible for debugging the equipment according to customers' requirements of various technical data. Our engineers will train our customers about equipment features and operation key points to make sure the equipment running in the best condition.
after-sale service
We provide installation, debugging, maintenance, training and other services; Provide relevant technical data, equipment, software and related GMP certification materials;Set up after-sales service hotline, and arrange personnel to visit customers every year to know more customer needs,like customer operation problems in the process of production equipment.
quality promise
Our company promises strictly operate the ISO9001 quality system certification standards and pharmaceutical equipment GMP audit requirements,promise we provide new equipment. Advanced technology,good quality.Equipment operation safe reliable, affordable, easy to maintain.
Equipment warranty period is one year,all the parts for the equipment choose well-known brand.During the warranty when equipment have problem in quality like equipment failure and damage,the company for free maintenance or replacement.
We look forward to cooperating with partners from all over the world to build win-win cooperation relationship in long term. Welcome for your visiting.
Previous Exhibition
FAQ:
1. Q: Please describe your warranty period.
A: 15 months after the equipment is arrived at the destination port or 12 months after the installation and commissioning of the equipment, whichever comes first.
2. Q: Do you provide on-site installation and commissioning?
A: Yes, we do. If on request, we'll provide the guidance of on-site installation and commissioning. Usually one mechanical engineer and one electrical engineer to assist.
3. Q: How about the cost of on-site installation and commissioning guidance?
A: The cost consists of round-trip air tickets, room and board expenses, service cost (labor cost), and site transportation (or directly provided by client), which shall be paid additionally.
4. Q: Are you a factory or a trading company?
A: We are a professional manufacturer. We have own factory and pilot plant for customers to do sample testing.

---
