UPS High Frequency UPS 1-10kVA Battery Backup Online UPS Uninterruptible Power Supply UPS

Product Description

Online high frequency single phase three phase UPS power supply for industrial equipment
Main Features
· Double conversion topology technology, pure sine wave output.
· Advanced DSP digital control technology.
· Environmental Friendly and energy saving, as the input power factor is up to 0.99.
· Wide input voltage and frequency range, 110 -- 240Vac, 40 -- 70 Hz.
· 0ms Line-Bat transfer , ensure the safety and reliablity of load.
· ECO mode optional, reduce the UPS power consumption.
· Low audible noise (below 50 dB), will not affect your daily life.
Specfictations

Model	1K	2K	3K	6K	10K
Phase	Single phase with ground
Input
Rate capacity	1KVA/900W	2KVA/1.8KW	3KVA/2.7KW	6KVA/6KW	10KVA/10KW
Rate voltage	110/115/120/127VAC or 220/230/240VAC			220/230/240VAC
Turn on voltage range	55-150VAC or 110-300VAC ≤50% load			110-300VAC ≤50% load
	80-150VAC or 160-300VAC ≤100% load			176-300VAC ≤100% load
Frequency range	40~70Hz			46~54Hz or 56~64Hz
Power factor	≥0.99 100% load
THDI	≤5%			≤4%
Output
Rate voltage	110/115/120/127VAC or 220/230/240VAC			220/230/240VAC
Voltage regulation	±1%
Line mode frequency	47~53Hz or 57~63Hz			46~54Hz or 56~64Hz
Bat mode frequency	50Hz or 60Hz ±0.1Hz
Voltage harmonic	≤2% R load			≤1% R load
	≤4% RCD load			≤4% RCD load
Crest ration	3:1
Line-Bat transfer	0ms
INV-Bypass transfer	≤4ms			0ms
Over load	100%±5%<load≤110%±5%:10min;110%±5%< load ≤130%±5%:1min;load>130%±5%:1s; ( transfer to bypass and alarm) Note: 6-10K line mode
Efficiency
Line mode	> 90%	> 91%	> 91%	> 94%	> 94%
Bat mode	> 89%	> 89%	> 90%	> 91%	> 91%
Bat
Number	3	6	8	16 or 20(20 only long)
Charger voltage	41.0VDC	82.1VDC	109.6VDC	218.4VDC/273VDC
Charge current (stand)	1.5A		1.2A	1A
Charge current(long)	1A/2A/4A/6A/8A(adjustable)			4.0A
Size and weight
Stand UPS(mm)	397*145*220	421*190*318	421*190*318	369*190*688/	442*190*688
Weight(kg)	12	22.5	32.2	54	66
Long time UPS(mm)	397*145*220	421*190*318		369*190*318	442*190*318
Weight(kg)	6.3	10.5	11.7	13	16
Environment
Work temperature	0ºC~40ºC
Work humidity	20%~95%
Audible noise	≤50dB			≤55dB	≤58dB
Communication	RS-232/USB/SNMP card adjustable
