Product Details
Product Description
Product Description
White corundum manufacture from China with 24 years experience
White fused alumina is one of the most commonly used abrasive material for abrasive tools. The white fused alumina F grit could be used for boneded abrasives such as cutting wheels, grinding wheels, vitrified grinding wheels, whetstones, etc. White fused alumina are made by a process of high temperature melting aluminium oxide method in a fixing furnace. It is of excellent self-sharpening property, good toughness and aggressive grinding ability.
Typical chemical analysis of White Fused Alumina (F46)
AL2O3
| 99.62%
|
Fe2O3
| 0.02%
|
Na2O
| 0.18%
|
K2O
| 0.01%
|
SiO2
| 0.07%
|
CaO
| 0.02%
|
MgO
| 0.01%
|
L.I.O.
| 0.05%
|
Typical physical properties of White Fused Alumina (F46)
Hardness:
| Mohs:9.0
|
Maximum service temperature:
| 1900 centigrade
|
Melting Point:
| 2250 centigrade
|
Specific Gravity:
| 3.95g/cm3
|
Volume density
| 3.6g/cm3
|
Bulk density(LPD):
| 1.70g/cm3
|
Whiteness:
| 85%
|
Milling Roughness:
| 33.6%
|
Particle shape:
| Angular
|
Bulk density of White fused alumina:
F Grit Size
| Mean diameter in um
| Bulk Density(LPD) in g/cm3
|
F8
| 2460
| 1.79-1.88
|
F10
| 2085
| 1.78-1.88
|
F12
| 1765
| 1.78-1.87
|
F14
| 1470
| 1.77-1.86
|
F16
| 1230
| 1.75-1.85
|
F20
| 1040
| 1.74-1.85
|
F22
| 885
| 1.73-1.84
|
F24
| 745
| 1.73-1.83
|
F30
| 625
| 1.73-1.82
|
F36
| 525
| 1.72-1.82
|
F40
| 438
| 1.71-1.81
|
F46
| 370
| 1.70-1.80
|
F54
| 310
| 1.68-1.79
|
F60
| 260
| 1.68-1.78
|
F70
| 218
| 1.63-1.73
|
F80
| 185
| 1.61-1.71
|
F90
| 154
| 1.59-1.69
|
F100
| 129
| 1.58-1.68
|
F120
| 109
| 1.55-1.62
|
F150
| 82
| 15.2-1.61
|
F180
| 69
| 1.50-1.60
|
F220
| 58
| 1.48-1.58
|
Product Feature of White Fused Alumina
1. Excellent self-sharpening ability.
2. High hardness.
3. Easy to mix with colorant to get color wheels.
4. Good grinding ability. It will get sharp grinding of abrasive wheels.
5. High Al2O3 purity with low Na2O and low SiO2
6. Suitable for a large range of substrate including stainless steel, iron, metal, steel, etc.
Applications of White Fused Alumina
1. Resin bonded cutting and grinding discs.
2. Depressed center grinding wheels.
3. Fiber discs.
4. Sanding blocks.
5. Vitrified grinding wheels.
6. Net grinding wheel
7. Polishing wheels.
8. Whetstone and lapping stone.
9. Polishing wax.
10. Mounted point.
Product Specification of White Fused Alumina
Grit size
| Sieve 1
| %
| Sieve 2
| %
| Sieve 3
| %
| Sieve 4
| %
| Sieve 5
| %
|
F8
| +4000um
| 0
| +2800um
| ≤20%
| +2360um
| ≥45%
| +2360+2000um
| ≥70%
| -1700um
| ≤3%
|
F10
| +3350um
| 0
| +2360um
| ≤20%
| +2000um
| ≥45%
| +2000+1700um
| ≥70%
| -1400um
| ≤3%
|
F12
| +2800um
| 0
| +2000um
| ≤20%
| +1700um
| ≥45%
| +1700+1400um
| ≥70%
| -1180um
| ≤3%
|
F14
| +2360um
| 0
| +1700um
| ≤20%
| +1400um
| ≥45%
| +1400+1180um
| ≥70%
| -1000um
| ≤3%
|
F16
| +2000um
| 0
| +1400um
| ≤20%
| +1180um
| ≥45%
| +1180+1000um
| ≥70%
| -850um
| ≤3%
|
F20
| +1700um
| 0
| +1180um
| ≤20%
| +1000um
| ≥45%
| +1000+850um
| ≥70%
| -710um
| ≤3%
|
F22
| +1400um
| 0
| +1000um
| ≤20%
| +850um
| ≥45%
| +850+710um
| ≥70%
| -600um
| ≤3%
|
F24
| +1180um
| 0
| +850um
| ≤25%
| +710um
| ≥45%
| +710+600um
| ≥65%
| -500um
| ≤3%
|
F30
| +1000um
| 0
| +710um
| ≤25%
| +600um
| ≥45%
| +600+500um
| ≥65%
| -425um
| ≤3%
|
F36
| +850um
| 0
| +600um
| ≤25%
| +500um
| ≥45%
| +500+425um
| ≥65%
| -355um
| ≤3%
|
F46
| +600um
| 0
| +425um
| ≤30%
| +355um
| ≥40%
| 355+300um
| ≥65%
| -250um
| ≤3%
|
F54
| +500um
| 0
| +355um
| ≤30%
| +300um
| ≥40%
| +300+250um
| ≥65%
| -212um
| ≤3%
|
F60
| +425um
| 0
| +300um
| ≤30%
| +250um
| ≥40%
| 250+212um
| ≥65%
| -180um
| ≤3%
|
F70
| +355um
| 0
| +250um
| ≤25%
| +212um
| ≥40%
| +212+180um
| ≥65%
| -150um
| ≤3%
|
F80
| +300um
| 0
| +212um
| ≤25%
| +180um
| ≥40%
| +180+150um
| ≥65%
| -125um
| ≤3%
|
F90
| +250um
| 0
| +180um
| ≤20%
| +150um
| ≥40%
| +150+125um
| ≥65%
| -106um
| ≤3%
|
F100
| +212um
| 0
| +150um
| ≤20%
| +125um
| ≥40%
| +125+106um
| ≥65%
| -75um
| ≤3%
|
F120
| +180um
| 0
| +125um
| ≤20%
| ≥40%
| ≥40%
| +106+90um
| ≥65%
| -63um
| ≤3%
|
F150
| +150um
| 0
| +106um
| ≤15%
| +75um
| ≥40%
| +75+63um
| ≥65%
| -45um
| ≤3%
|
F180
| +125um
| 0
| +90um
| ≤15%
| +75um
| *
| +75+63um
| ≥40%
| -53um
| *
|
F220
| +106um
| 0
| +75um
| ≤15%
| +63um
| *
| +63+53um
| ≥40%
| -45um
| *
|
Size
| D3(um)
| D50(um)
| D94（um)
|
F230
| ＜82
| 53.0±3.0
| >34
|
F240
| ＜70
| 44.5±2.0
| >28
|
F280
| ＜59
| 36.5±1.5
| >22
|
F320
| ＜49
| 29.2±1.5
| >16.5
|
F360
| ＜40
| 22.8±1.5
| >12
|
F400
| ＜32
| 17.3±1.0
| >8
|
F500
| ＜25
| 12.8±1.0
| >5
|
F600
| ＜19
| 9.3±1.0
| >3
|
F800
| ＜14
| 6.5±1.0
| >2
|
F1000
| ＜10
| 4.5±0.8
| >1
|
F1200
| ＜7
| 3.0±0.5
| >1(at 80%)
|
F1500
| ＜5
| 2.0±0.4
| >0.8(at 80%)
|
F2000
| ＜3.5
| 1.2±0.3
| >0.5(at 80%)
|
Packing of White Fused Alumina
1. 25KGS/PVC Bag
2. 1Metric Ton/Jumbo Bag
3. 25KGS/PVC Bag,40Bags/Jumbo Bag
4. 1 Metric Ton/Jumbo Bag/Pallet
5. Other customized packages are available
FAQ
Q: Are you a manufacturer or trading company?
A: We are a manufacturer of white fused alumina. HAIXU Abrasives has white fused alumina manufacturing experience of 22 years. We produce WFA section sand, WFA grains, WFA powder, etc.
Q: Are the White fused alumina grains you get is produced from a Tilting furnace or a Fixing furnace?
A: Our White fused alumina grains F8-F220 are produced from fixing furnaces. Fixing furnace White fused alumina is of higher toughness and more durable.
Q: What is the content of Na2O of your white fused alumina grains?
A: We have normal Sodium WFA grain and low Sodium WFA grain. Normal WFA grain Na2O content is max. 3% which is lower than most competitors. Low sodium WFA grain Na2O content is max.0.1%.
Q: Do you have a MOQ of WFA grain?
A: Generally no limit of MOQ. Even 25kgs(1 bag)is ok for us. But the logistic cost will be higher than normal.
Q: How do you make quality control on White fused alumina before delivery?
A: We will check the quality of white fused alumina including chemical content, particle size distribution, milling toughness of white fused alumina, Bulk density of white fused alumina, the whiteness of white fused alumina, etc.
Q: What is the lead time of FCL White fused alumina?
A: Generally 7-10 days after receiving the deposit.
>>
