Automatic 4 Side Planer Six 6 Spindle Four Side Moulder Planer

Product Description

Model		HJD-M623A
Machine parameter	Working width	25-230mm
	Working thickness	8-150mm
	Work table size	1950mm
	Feeding speed	7-28m/min
	Main spindle diameter	Φ40mm
	Rotary speed of main spindle	6000r/min
	Air pressure	0.6MPa
Motor power	1st Lower spindle	7.5kw
	1st Upper spindle	11kw
	Right vertical spindle	7.5kw
	Left vertical spindle	7.5kw
	2nd Lower spindle	7.5Kw
	2nd Upper spindle	7.5Kw
	Beam lifting motor	0.75kw
	General Power	54.75Kw
	Feeding motor	4kw
Cutter diameter	1st Lower spindle	Φ125mm
	1st Upper spindle	Φ125-200mm
	Right vertical spindle	Φ125-200mm
	Left vertical spindle	Φ125-200mm
	2nd Lower spindle	Φ125-200mm
	2nd Upper spindle	Φ125-200mm
Others	Feeding roller diameter	Φ140mm
	Dust pipe diameter	Φ140mm
	Dimension	4350*1635x1735mm
	Weight	3710kg

Stepless feeding is adopted, and the feeding speed is 4 to 18 meters/minute;
Each spindle is driven by an independent motor, and the cutting force is quite strong;
All spindles are arranged in the front, and it is convenient to operate;
Made of ultrahard mold steel, the worktable is durable;
The whole hard worktable is convenient to maintain;
A short material auxiliary device is equipped, so that the short materials can be smoothly charged;
Lower active rollers improve the feeding effect;
Internationally famous electric elements ensure high stability;
A fully closed safety protective shield helps to avoid wood dust flying and isolate noise, and has a safety protection effect;
Pneumatic pressing type feeding wheels are arranged, and the pressing force can be adjusted in segments, so that wood of different thicknesses can be smoothly fed;

---
