| US$9,800.00 | 1 Piece (MOQ) |
| Specifications |
| Swing over bed 660mm |
| Swing over cross slide 440mm |
| Swing over gap 900mm |
| High speed precision heavy duty lathe C6266X3000 |
| Swing over bed 660mm |
| Swing over cross slide 440mm |
| Swing gap 900mm |
| Length of gap 250mm |
| Center height 330mm |
| Distance between centers 1500/2000/3000mm |
| Width of bed 400mm |
| Max section of tool 25mmx25mm |
| Max travel of cross slide 368mm |
| Max travel of compound rest 230mm |
| Headstock |
| Spindle bore 105mm |
| Spindle nose D1-8 |
| Taper of spindle bore 113mm MT5 |
| Spindle speed number 16 |
| Range of spindle speed 25-1600rpm |
| Leadscrew pitch 40mmx2TPI or 40mmx12mm |
| Inch threads range 7/16 - 80TPI (54kinds) |
| Metric threads range 0.45-120mm(54kinds) |
| Diametrical pitches range 7/8-16DP(42kinds) |
| Module pitches range 0.25-60MP(42kinds) |
| Longitudinal feeds range in metric leeadscrew 0.044-1.48mm/rev(25kinds) |
| Longitudinal feeds range in inch leadscrew 0.00165"-0.05497"rev(25kinds) |
| Cross feeds range in metric leadscrew 0.022-0.74mm/rev(25kinds) |
| Cross feeds range in inch leadscrew 0.00083"-0.02774"/rev(25kinds) |
| Quill travel 235mm |
| Quill diameter 90mm |
| Quill taper MT5 |
| Main motor power 7.5kw |
| Coolant pump motor 0.09kw |
| Overal dimension 321/371/471X123X160cm |
| Packing size 324/374/474X114X184cm |
| Net weight 3060/3345/3710kgs |
| Gross weight 3535/3835/4310kgs |
