| BATTERY | Battery Voltage | 48VDC |
| Battery Type | Lithium/Lead-acid | |
| INVERTER OUTPUT | Rated Power | 5000VA/ 5000W |
| Parallel Capability | Yes, 6 units maximum | |
| AC Voltage Regulation (Battery Mode) | 230VAC ± 5% @ 50/60Hz | |
| Surge Power | 10000VA | |
| Efficiency (Peak) | 93% | |
| Waveform | Pure sine wave | |
| Transfer Time | 10ms typical, 20ms Max | |
| SOLAR CHARGER | Maximum PV Array Power | 6000W |
| MPPT Range @ Operating Voltage | 120VDC ~ 430VDC | |
| Number of Independent MPP Trackers/Strings Per MPP Tracker | 1/1 | |
| Maximum PV Array Open Circuit Voltage | 450VDC | |
| Maximum Solar Charge Current | 100A | |
| AC CHARGER | Charge Current | 80A |
| AC Input Voltage | 230 VAC | |
| Selectable Voltage Range | 170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliances) | |
| Frequency Range | 50Hz/60Hz (Auto sensing) | |
| PHYSICAL | Protection Degree | IP20 |
| Dimension (W/H/D) | 330/485/135mm | |
| Net Weight | 12kgs | |
| OPERATING ENVIRONMENT | Humidity | 5% to 95% Relative Humidity(Non-condensing) |
| Altitude | <2000m | |
| Operating Temperature | 0°C - 55°C | |
| Storage Temperature | -15°C - 60°C |
| Number | Product Name |
| 1 | LCD display |
| 2 | Status indicator |
| 3 | Charging indicator |
| 4 | Fault indicator |
| 5 | Function buttons |
| 6 | AC input |
| 7 | WiFi/GPRS communication port |
| 8 | USB communication port |
| 9 | BMS communication port (support CAN/RS485 protocol) |
| 10 | RS485 communication port (for expansion) |
| 11 | Dry contact |
| 12 | PV input |
| 13 | Power on/off switch |
| 14 | Battery input |
| 15 | Parallel communication ports |
| 16 | Current sharing ports |
| 17 | AC output |
| 18 | Circuit breaker |
