High-Precision Automatic Paper Roll Cutting Machine for Efficient Production

Product Description

Servo Precision High Speed Roll Paper Cutting Machine(two reels)
Machine configuration:
1.High-Precision Single-Knife Paper Cutter (1 Set)
2.Static Electricity Elimination System (1 Set)
3.Automatic Counting Label Insertion System (1 Set)
4.Automatic Paper Gathering Equipment (2 Sets)
5.Electrical System (1 Set)
6.Driving Motor System (1 Set)
7.Top Cone Shaftless Paper Mill Roll Stand (2 Rolls)
8.Operating System: Human-Machine Interface Display (1 Set)
9.Main Drive Control System (1 Set)
10.Paper Conveying System (1 Set)
11.Paper Angle Automatic Adjustment Function (1 Set)
12.Automatic Tension Adjustment System (1 Set)
13.Automatic Paper Jamming Emergency Stop Device (1 Set)
14.Hand-Cranked Adjustment Of Paper Patting Device (1 Set)
15.Automatic Speed Down Function Of Paper Core
16.Tools And Random Spare Parts (1 Set)
Technical specification:

Model	SPEEDCUT-1450ZN
Cutting type	The up knife cut reciprocally and the down knife is fixed
Paper weight	50-550g
Cutting precision	Cutting length 1000mm±0.2mm
Maximum cutting speed	0-350cuts/min
Gross weight	10,000kgs
Power supply	380V/220V×50Hz
Maximum cutting meters	350m or 350cuts/min
Cutting length range	450-1500 mm
Maximum reel diameter	1800mm(71")Max
Maximum web width	450-1450mm
Number of cut sheet widths	1 width
Requirement of air pressure source	0.8Mpa
Overall Dimension	10,000×3675×2330mm
Maximum Stacking Height	1600mm

---
