Electron Soldering Digital Screen Microscope Video Cheap Price for Mobile Phone Repair

US$280.00-385.00 2 Sets (MOQ)

Basic Info.

Model NO.
HD800MX
Magnification
50-100X
Type
Video
Number of Cylinder
Binoculars
Mobility
Desktop
Stereoscopic Effect
Stereoscopic Effect
Kind of Light Source
Ordinary Light
Usage
Teaching, Research, Repair
Principle
Optics
Principle of Optics
Video
Name
Microscope
Model
Sgo-HD800mx
Original
China
Brand
Kwongkuk
Transport Package
Foam+Carton
Specification
450x420x120
Trademark
KWONG KUK
Origin
China
HS Code
9011800090
Production Capacity
10000

Packaging & Delivery

Package Size
50.00cm * 45.00cm * 30.00cm
Package Gross Weight
8.000kg

Product Description

Product Description
Main function
Photograph Click the button to store the page photo to the storage device.
Preview Click the button to switch to the storage device to view photos or videos.
Setting Click the button to bring up the setting function page.
Measurement (optional) Click the button to bring up the measurement function page

Optical system Specifications		 Optical Len 5A set
Optical conversion ratio 1:6.4
Ratio of the objective 0.7X-4.5X
Camera eyepiece magnification 0.5X
Optical ratio 0.35X-2.25X
Video magnification 25X-170X
Field of view 1.5*2.8-11*19mm
Working distance 110mm
Center distance 150mm

CCD System specifications		 Resolution ratio 1920*1080P
Sensor size Samsung 1/3
Pixel size 2.75um*2.75um
Data bits 12BIT
Exposure mode Rolling shutter
HDR Tertiary enhanced
SE Third order edge enhancement
White balance Manual/Auto
Focus mode Manual
Output frame rate 60fps
Output mode HDMI
Output color Colours/black and white
Power output 12V1A
Fixed bracket system specifications Focusing frame Coarse moving focusing hand wheel,The focusing hand wheel is elastic and adjustable,Lift 0-65mm
Pillar stand Diameter 25*355mm
Working platform 380*255*23mm
Lighting System Specifications External light source LED ring light,input voltage:AV100-240V wide voltage,Adjustable brightness
Video display system specifications Screen size 21.5
Screen ratio 16:9
The image function Picture format BMP/JPG/PNG
Storage mode U dish
