GBDP-1600 High Efficiency Multi Blades Stone Cutting Machine/granite saw

Product Description

This machine adopts suspension-type structure, the rotating, feeding, and retrieving of the machine's blades as well as the bodily horizontal movement of the trolley are centrally controlled from an electric control unit, only slicing by manual, so it has high automation level, with excellent machining ability, stable performance as well as high efficiency and low energy consumption. It's widely used for the processing of granite slab.

Name	Unit	GBDP-1600A	GBDP-1600B	GBDP-1600C
No. of blade		12(6-1600mm+6-940mm)	16(8-1600mm+8-940mm)	20(10-1600mm+10-940mm)
Main motor power	kw	65	90	110
Track gauge of trolley	mm	1900	1900	2100
Max.cutting size	mm	3300x1300x650	3300x1300x650	3300x1300x650
Weight	kg	9000	9000	9500

Main Features
1) Machine with competitive price and high quality ,easy in installation and maintenance.
2) Adopting advanced world famous brand components in electric parts .
3) Guarantee for one year.
Our Service
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to install the machine, training how to use the machine.
* Engineers available to service machinery overseas.
FAQ
1. Do you have more stone machines?
Yes, we can produce all series of stone processing machines with competitive price and high quality.
2. Where is your factory?
Our factory locates in Xiangbei Industry Zone,Xiang'an,Xiamen,Fujian.
3. Do you have agent?
We don't have agent as we all sell directly to our customer, in this way, the customer can get lowest cost.
4. How much is this machine?
Please tell me your stone is granite or marble, the size, your destination port, so that I can quote you best price.
5. How long can I get my product?
Normally it takes 30 days to produce our products

---
