Non Wovenfabric Manufacturing Machinery for Medical and Health Products

Product Description

Non Wovenfabric Manufacturing Machinery for Medical and health products
Product Description
This polypropylene (PP) spunbonded nonwoven fabric production line has advantages of superior performance, beautiful color, and good quality. It can form a fibre web symmetrically and is complete in types. It can also add recycled material and stuffing to reduce the cost of products.
This equipment is used for polypropylene fiber spinning web, hot rolling and strengthening nonwoven fabric production. The melt hot-rolled PP nonwoven fabric with different colors, functions and applications are produced with polypropylene fiber as the main raw material, supplemented with color masterbatch and additives such as anti-oxidation, anti pilling and flame retardant. The production line can not only produce three-layer SSS polypropylene spunbonded nonwoven products, but also produce three-layer S-M-S and four-layer S-S-M-S products. At the same time, the production line can produce melt blown nonwoven fabric for mask by adding off-line melt blown device.
Detailed Photos
Production Application
Technical Advantages
1) The whole line is well-structured and easy to operate.
2) The whole line is highly automated.
3) Control elements are of well-know make, high performance and reliable technologies.
4) The whole line are controlled by PLC and operated with touch-screen.
5) The allocation of the main frame and auxiliary equipment can be special designed and adjusted according to customers requirement.
Specification

Model No.	YP-SSMS-1.6	YP-SSMS-2.4	YP-SSMS-3.2
SSMS(Product width)	1600mm	2400mm	3200mm
Equipment Size	38*31*12m	40*33*12m	42*35*12m
Speed	400m/min	400m/min	400m/min
Gram Weight	10-100g/m2	10-100g/m2	10-100g/m2
Yield (according to 70g/m2)	15T/Days	16T/Days	24T/ Days

Principle Diagram
Feeding→Extrusion Melting→filtering→metering→spinning→Cooling→Stretching→Web spreading→Thermal bonding→slitting→collecting-packing
