1.Grinding is accurate and rapid, easy operation with no skill to grind.
2.Economical price that greatly reduces the cost and improves the use effect.
3.With diamond grinding wheel, it can be equipped directly with an accurate angle and long service life.
4.The electrically controlled and powerful DC motor: stable frequency, strong horsepower and long service life.
5.Bearing shaft and locking unit.
6.The machine is set up with the function of adjusting a point (central point) size, which can effectively coordinate with the material of drill hole and the
rotation speed. It can control the quality precision and prolong the service life of the drill bit.
| Model | MR-26D |
| Grinding Range | (8)Φ13-Φ26(Φ32) |
| Point Angle | 90°(85°)~140° |
| Power | AC/220V |
| Motor | 250W |
| Speed | 4400rpm |
| Dimension | 50×26×27cm |
| Weight | 31kg |
| Standard Equipment | Grinding wheel :CBN (for HSS)×1 |
| Fourteen ER40 collets: Φ13,Φ14,Φ15,Φ16,Φ17,Φ18,Φ19,Φ20,Φ21,Φ22,Φ23,Φ24,Φ25,Φ26 |
| Collet chuck:(Φ8-Φ30)×1 |
| Option Equipment | Grinding wheel :SD (for Carbide) |
| ER 40 Collets: Φ8, Φ9, Φ10, Φ11, Φ12, Φ27, Φ28, Φ29, Φ30,Φ31,Φ32 |
| Collet chuck:Φ31-Φ32 |
