| US$25,000.00-48,500.00 | 1 Piece (MOQ) |
| Mixing Drum | |
| Mixing volume | 4.0 M3 |
| Geometrical volume | 6.0 M3 |
| Concrete output | 4 M3 / batch, 16 M3 / hour |
| Drum rotating speed | 18 rpm |
| Drum slewing angle | 270° |
| Adjust up and down | 20° |
| Engine | |
| Brand | YUNNEI(YUCHAI Engine optional) |
| Model | YN48GBZ |
| Type | 4-Cylinder inline,direct injection |
| Rated power | 92KW |
| Max torque | 445-455/1400-1600 |
| Chassis | |
| Structure | Integrated rigid chassis |
| Transmission system | Adopt 280 split torque converter gearbox,with hing ang low speed |
| Wheelbase | 2400 mm |
| Axles | 20-Ton reduction driving axle |
| Tyre size | Off road steel cord type, 1670-20 |
| Cabin | |
| Type | type closed front cab |
| Joystick control | Double-joystick control the hydraulic system |
| Weighing system | The loading cells are acting on the drum, and technical data are displayed on the shovel loader weigher inside the cabin. |
| Air conditioning system | Cooling & heating air conditioner |
| Water supply sysytem | |
| Max. water suction capacity | Self-priming hydraulic water pump |
| Water tank capacity | 2*250L |
| Electric system | |
| Battery: | 2x12V-100AH |
