Open TBR Tyre One Stage Building Machine Single Stage TBR Tire Building

Product Description

Three-drum All-steel Radial Truck Tire Building Machine 1.Uses
For one-time forming of all-steel radial truck tires.
2. Tire Type
R17.5-24.5
3. Capacity: 90 - 100 strips/shift
4. Controls
Mitsubishi Q series PLC, mobile CPU, CC-LINK fieldbus, and SSCENT servo system; can also use Siemens, AB, Rexroth, or other PLC and bus form, depending on customer's needs.
5. Main Features and Technical Parameters
Molding drum: mechanical down assembly, servo motor control.
Tire casing drum: servo motor control, accurate, stable speed, position, vacuum absorb.
Belt drum: servo motor control.
Tire casing transfer ring: servo motor drive, linear guide positioning, synchronous belt transmission.
Belt transfer ring: servo motor drive, ball screw transmission.
Feed frame: various, consisting of relevant unwinding, centering device, automatic length set, cutting and fitting device.
