1800mm ABA Po Film Blowing Machine with Double Auto Winder

US$65,000.00-85,000.00 1 Piece (MOQ)

Basic Info.

Model NO.

FM2-1800

Maximum Folding Width of Film

1700mm

Screw Diameter

65mm*1, 55mm*1

Automation

Automatic

Computerized

Machine Weight

10T

Certification

CE, ISO9001:2008

Machine Size

L*W*H: 5.5m * 3.4m * 6.5m

Voltage

380V 50Hz 3phase

Transport Package

Plastic Warp Film for Container Shipment

Specification

double layers

Trademark

Xiongqiu Plastic Machinery Co., Ltd.

Origin

Foshan, Guangdong Province

HS Code

8477300000

Product Description

2 engine ABA film blowing machine is widely used in componud film, insulated film and all kinds of agricultural film. Such thin film has good separation which is able to meet the quality requirements of following packaging and printing machines for films.

Model	FM-800	FM-1100	FM-1300	FM-1700	FM-1800	FM-2000
suitable material	LDPE / LLDPE / HDPE
thickness	0.02---0.20mm
film width	750mm	1000mm	1200mm	1500mm	1700mm	2000m
max output	65kgs/hr	85kgs/hr	125kgs/hr	150kgs/hr	175kgs/hr	250kgs/hr

Extruder
screw diameter	Φ45mm*2	Φ50mm*2	Φ55mm*2	Φ65mm*2	Φ70mm*2	Φ75mm*2
L/D rate	30:1
temp. controller	10 zone	10 zone	10 zone	12 zone	12 zone	13 zone
barrel cooling	120w*4	120w*4	120w*4	120w*4	250w*6	250w*6
driving motor	11kw*2	15kw*2	18.5kw*2	22kw*2	30kw*2	30kw*2

Die head
die diameter	Φ180mm	Φ250mm	Φ250mm	Φ350mm	Φ450mm	Φ630mm
air ring diameter	Φ280mm	Φ350mm	Φ350mm	Φ450mm	Φ550mm	Φ900mm
die structrue	Spiral mandrel die chrome plated surface 40Cr
cooling fan	1.5kw	1.5kw	2.2kw	3kw	4kw	4kw

Take up part
take up width	800mm	1100mm	1300mm	1700mm	1800mm	2200mm
effective width	700mm	1000mm	1200mm	1600mm	1700mm	2100mm
take up motor	1.5kw	1.5kw	1.5kw	2.2kw	2.2kw	3.7kw

Winder
winder width	800mm	1100mm	1300mm	1700mm	1800mm	2200mm
effective width	700mm	1000mm	1200mm	1600mm	1700mm	2100mm
winder motor	30kg	30kg	50kg	50kg	80kg	100kg
optional equipment	auto-loader, film surface treater, air compressor,fast change net, double-center rewinder/auto rewinder, flat winder with row roller, rotary die head and double-wind air ring.

PICTURES FOR REFERENCE:
