Automatic Plastic Injection Moulding Machine for PVC Pipe Fitting

Product Description

Injection Molding Machine
(Model: SZ-950A)

Screw diameter	mm	30	35	40
Shot weight	gram	103	140	183
Injection capacity	cm3	113	154	201
Injection pressure	kg/cm2	2490	1830	1400
Screw stroke	mm	160
Screw Speed	rpm	0-260
Screw torque	N.m	510
Heating power	kw	7.3
Clamping force	ton	95
Opening stroke	mm	340
Mould height	mm	135~380
Space between tie bars	mm	360×360
Ejector force/stroke	KN/mm	25.4/80
Oil pump motor	kw	11
Machine Size	m	4.25×1.2×1.8
Packing size	m	4.5×1.3×2.1
Machine weight	ton	3

Advantages of small injection molding machine
1 HIGH LOAD OIL BEARING
The movable part of machine hinge and sliding adopt oil-bearing, decrease the use of lubricating oil, reduce maintenance costs and reduce oil to enhance the clean lines of the machine.

2 SYNCHRONOUS HYDRAULIC PRECISION MOULD ADJUSTMENT MECHANISMS
Hydraulic motor, the center location of gear module mould adjustment system, enable the mold adjustment system more perfect.

3 INTELLIGENT DISPLACEMENT DISTRIBUTION OF LUBRICATION SYSTEM
Intelligent displacement oil distribution system, equal distribution of oil and high efficiency of lubrication, extension the life of the reamer.

4 DESIGN AND RESERVE LARGE AUXILIARY SPARE SPACE.
Convenience of the circuit connection for the precision mold of electricity, gas, water oil and configuration flexible delivery device.

5 ADJUSTABLE JUNIOR WARE-RESISTING FEET SLIP
Adjust special polymer wear-resisting materials containing flattering feet, adjustable height, balance weight, durable, and clean.

---
