Product Details
Product Description
Product Description
This device is a contrast media delivery system indicated for the administration of intravenous contrast media into human bodies in conjunction with MR scanner (magnetic resonance imaging). ANTMED continually pushes to develop technologies that enhance the quality of scans and streamline the workflow for technicians. ImaStar series is a complete line that includes CT single-head, CT dual-head, DSA and MR injectors with pedestal and ceiling mount options.
Features:
Four language options: English, French, Italian, Chinese
Independent dual motor drive system: allows independent of filling, air expelling and injections of Side A and Side B respectively
True Color 12.1′ Touch Screen: simple and intuitive user interface highlights key information to facilitate setup and injections
Waterproof Injector Head: prevents injector damage caused by leakage and ensures safe clinical operation
Bluetooth Communication
Operational Safety: air expel panel and ready panel are separated for double confirmation to ensure safe injection; when approaching Pressure Limit, the system automatically lower injection speed; when exceed Pressure Limit, the system stops injection, and triggers both text and vocal alarms
Requires No Battery
Independent KVO Mode: flexible KVO interval settings available; 115ml saline syringe capacity allows longer KVO
Real-time Pressure Curve: provides real-time pressure curve, monitor pressure changes, and reduce risks of patients
To be supplied with two sets of standard disposables; sufficient to cover the operational training and the start-up period.
MRI Compatibility Up to 3 Tesla
Advantages:
Provides reliable performance, safe patient experience and price affordability in MRI imaging.
Independent Keep Vein Open (KVO) allows more time to focus on the patient
Wireless technology enables quick installation and easy positioning and frees the room from cable clutter
Easy to operate-English interface, dual screen display, scanning room and operation room can be operated simultaneously
Decrease the amount of contrast agent and lower radiation.
Lower per-patient cost. Affordable injector prices and syringe consumables are cheaper
Specifications:
Power Supply： 100-240VAC，50/60Hz，200VA
Flow Rate ： 0.1-10ml/s
Pressure Limit： 325PSI
Piston Rod speed: 9.9ml/s
Auto filling Rate： 8ml/s
User programmable injection sequenties: 6
Injection Records: 100 (The storage records will be kept even when the system is power-off.)
Injection Program: 100
Injection delay: 1-300s
Scan delay:1-300s
KVO Available options: every 15 sec, 20 sec, 30 sec, 45 sec, 60 sec,75 sec
Syringe Volume： 1-65ml, 1-115ml
Components/Materials
|
Part
| Description
| Qty
| Material
|
Scan room unit
| Injector
| 1
| 6061 Aluminum and ABS PA-757(+)
|
Control room unit
| Touch display screen
| 1
| ABS PA-757(+)
|
Order Information:
Warranty: one year
Packaging:
Quantity/Carton 1set
Weight/Carton 105 KGS
Carton Size 133mm*57mm*76mm
Certificate: CE, FSC and ISO 13485
Supply Ability :55 Sets per Month
Delivery Detail: Within 15 days upon payment receipt
Brand Name: ANTMED
Place of origin: Shenzhen, China
>>
