US$15,000.00-65,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Model NO.
6m3 Concrete Transport Truck
Machining Process
Welded Molding Machine
Certification
ISO9001: 2000, CE
Dimension(L*W*H)
7370X2500X3650mm
Engine Manufacturer
Dongfeng Cummins Engine Co., Ltd (Dcec)
Hydraulic Driving System
Imported, International Famous Brand
Transport Package
Standard Packing for International Transport
Specification
ISO certified
Production Capacity
20 Sets Per Month
Product Description
Dongfeng 4X2 6m3 concrete transport truck with Cummins Engine:
1.3m3, 4m3, 6m3
2. Cummins Engine, DCEC made
3. Imported Hydraulic System
Characteristics of Dongfeng 4X2 6m3 concrete transport truck with Cummins Engine:
1. Cummins Engine( DCEC Made) and Yuchai Engine are available for small concrete mixer truck vehicle.
2. Mixing Capacity of Dongfeng 4x2 small concrete mixer truck vehicle: 3m3, 4m3, 6m3
3. Drive type: 4x2, LHD(Left Hand Driving) or RHD( Right Hand Driving) chosen by customers.
4. Imported hydraulic system of International famous brand, you can get Spare Parts all over the world easily.
Photos of DCEC / Cummins Engine 6m3 Transit Mixer with dongfeng 4x2:
| [ Main Technical Parameter ] |
| Chassis Brand | DONGFENG | Batch No. | 257 |
| Product Name | EQ5168GJBL Concrete Mixer Truck | Truck Model | ZL2TH4D7011 |
| Total weight(Kg) | 16000 | Tank Volume(m3) | 3 |
| Rated Load(Kg) | 7550 | Dimension(mm) | 7370×2500×3650 |
| Curb Weight(Kg) | 8255 | Passenger(person) | 3 |
| Approach angle/departure angle(°) | 30/31 | Front overhang/rear overhang(mm) | 1250/2020 |
| Axel No. | 2 | Wheelbase(mm) | 4100 |
| axle load (Kg) | 6000/10000 | Max. Speed(Km/h) | 90 |
| Other | Mixing Volume:3m3
Material of side and below protective device:Q235-A,
Connection type: Bolt Connection
Height of back protective device:430mm |
| [ Chassis Parameter ] |
| Chassis Model | EQ1168GLJ3 | Brand | DONGFENG |
| Dimension(mm) | 7250x2462x2740 | Quantity of Tire | 6 |
| Approach angle/departure angle(°) | 30/26 | Tire specification | 9.00-20 |
| Steel Spring No. | 8/10+8 | Front Tread(mm) | 1940 |
| Fuel | Diesel | Back Tread(mm) | 1860 |
| EMISSION STANDARD | Euro III |
| Engine Model | Engine Manufacturer | Displacement(ml) | Power(Kw) |
| ISB180 40 | Dongfeng Cummins Engine Co., LTD (DCEC) | 5900 | 132 |
>>
