UV/300 PVC I Njection Molding Machine

US$1.00-2.00 1 Piece (MOQ)

Basic Info.

Model NO.
UV/300
Plastic Type
Thermoplastic
Plasticizing Way
Screw Type
Clamping Way
Hydraulic & Mechanical
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008
Certificate of Origin
1
Certificate of Fumigation
1
Packing List
1
Commercial Invoice
1
Easy Broken Parts
1
Transport Package
Wooden Pallet and Dust Cover
Trademark
K&E
Origin
China
HS Code
8477101090
Production Capacity
200/Y

Product Description

PVC IMM :
Cooling fan installed on barrel,Widened protective door.,Increased motor.
The main production of PVC material pipe fittings
Parameters:
PVC STYLE SPECIFICATION UV/300
SCREW TYPE A B C
Injection Unit
Screw diameter mm 55 60 65
Screw L/D ratio L/D 24 22 20.3
Shot volume(theoretical) CM3 676 805 945
Injection weight(PVC) g 861 1026 1204
Injection rate g/s 314 372 437
Injection pressure MPA 202 170 145
Screw speed rpm 130
Clamping Unit
Clamping force KN 3000
Open stroke mm 610
Space between tie-bars(W*H) mm 650*650
Max mould height mm 630
Min mould height mm 200
Ejector stroke mm 170
Ejector force KN 70
Others
Max pump pressure MPA 16
Pump Motor power KW 33
Heating power KW 18.3
Numbers of heating area Segment 3+1
Machine dimension(L*W*H) M 6.55*1.72*2.45
Oil tank cubage L 385
Machine weight TON 10

Configuration List:
Name Brand
Computer KEBA(AUSTRIA) or EST
Servo Drive INOVANCE(CHINA)
Servo Pump SUNNY(USA) / SUMITOMO(JAPAN)
Servo Motor PHASE(ITALY)
Electro-hydraulic Proportion valve HNC (Taiwan)
Stroke transducer NOVO or Miran(GERMANY)/GERFRAN(ITALY)
Breaker Schneider (FRANCEN)/Siemens(GERMANY)
Contacts Schneider (FRANCEN)/Siemens(GERMANY)
Switch Schneider (FRANCEN)/Siemens(GERMANY)
Hydraulic Direction Valve Vickers (USA) or Rexroth (GERMANY)
Plasticing Motor DINAMIC(ITALY) or STF(ENGLAND)
Hydraulic Hose MANULI(ITALY)/CONTINENTAI(GERMANY)
Plasticing speed sensor OMRON
Sealing ring HALITE or TREIIEBORG(UK or GERMANY)
