| US$3.00-5.00 | 1 Piece (MOQ) |
| Model | 3V210-08 |
| Position and way NO. | 3/2 way |
| Effective area | 14mm2(CV=0.78) |
| Port size | Air inlet=Air outlet=Exhaust=G1/8" |
| Fluid | 40 micron filtered air |
| Operation | Inside pilot type |
| Operating pressure | I0.15~0.8MPa |
| Max.proof pressure | 1.2MPa |
| Temperature | 5~50 C |
| Allowable boltage | ±10% of rated voltage |
| Power consumption | AC:2.5VA DC:2.5W |
| Coil insulation &protection grade | Class F.IP65 |
| Electriacl entry | Lead wire or connector |
| Higest action frequency | 5 cycle/second |
| Shortest excitation time | 0.05 second |
