1450*912*1200mm High Power Winding Machine in Blue & Green

Product Description

Introducing the Electric Winding Machine (DLM-0866), a technological marvel meticulously engineered to elevate your winding processes to unprecedented levels of efficiency and performance.
Presenting the DLM-0866 Coil Winding Machine, expertly crafted for unparalleled precision and efficiency in every winding task, ensuring consistent quality.
1. Advanced Array Motor: Experience the exceptional dynamic performance delivered by our cutting-edge array motor technology.
2. Automatic Computer Control: Effortlessly automate your winding processes with our sophisticated and highly intuitive computer control system.
3. Super Quality: Experience unmatched excellence in both design and function, ensuring the highest quality in every coil produced.
Introducing the DLM-0866 Large Winding Machine, where substantial size meets impeccable functionality and advanced engineering.
1. This horizontal and automatic winding machine, equipped with serial parallel coil formers, is perfectly designed for a wide variety of applications, including AC and DC motor stator coils and inductance coils.
2. At its core lies a single board computer, expertly managing tasks such as zero resetting, traversing, and skipping, ensuring precision and optimal operation.
3. User-Friendly Control Panel: Effortlessly tailor your settings by adjusting wire diameter, number of turns, and traverse and skipping distances, all customized to meet your specific requirements.
Technical Parameter: Discover the exceptional specifications that define the superior capabilities of our machine, setting new standards.
Suitable Wire Diameter: Engineered to seamlessly handle wire diameters ranging from 0.1 to 1.2 mm, accommodating a variety of needs.
Winding Width: Offers a versatile winding width from 0 to 30 mm, addressing diverse application requirements with precision.
Winding Diameter: Accommodates winding diameters ranging from 25 to 180 mm, providing unmatched flexibility for various tasks.
Effective Length of Series-mode Axis: Offers an expansive range of 500 to 600 mm, significantly enhancing performance and adaptability.
Return Diameter of Former: Supports return diameters spanning 210 to 280 mm, optimizing efficiency for superior operation.
Rotation Speed: Amplify your operations with a powerful rotation speed of 3200 R.P.M., enhancing productivity.
Power Source: Dependable 220V 50Hz power source, ensuring consistent and stable operation for all tasks.
Pressure of Air Supply: Functions efficiently within an air supply pressure of 0.5-0.8 MPa, guaranteeing optimal performance.
Power: Utilize the robust power of 750W to accomplish tasks with remarkable precision and reliability.
Dimension (L x M x H): Compact yet efficient, with dimensions of 1450 x 912 x 1200 mm, ideal for various setups.
Weight: Weighing approximately 800 kg, this machine is robust yet manageable, suitable for diverse industrial environments.

---
