SLD-200 200KW/340Hp/IP55 Power frequency-single stage 380v50HZ screw air compressor

Product Details

Product Description

Product Description
Product introduction video
SLD-200 Performance Parameters Table

NO	Item		Unit	parameters	remarks
1	Volume flow/rated exhaust pressure		（m3/min）/ MPa	33.50/0.7 30.00/0.8 27.10/1.0 20.05/1.25
2	ambient temperature		℃	-5～+40
3	type of cooling			Air cooling
4	Discharge Temperature		℃	≤Environmental temperature+15
5	Lubricant quantity		L	100
6	Transmission method			Direct connection
7	Air volume adjustment method			On-off regulation
8	Oil content of gas		ppm	≤3
9	Noise		dB(A)	85±2
10	Lubricant brand			UNICOL
11	Safety valve set pressure		MPa	rated working pressurex1.1
12	Motor	Power	kW	200
		Voltage	V	380
		Start-up method		Y-△
		Rated speed/frequency	rpm/Hz	3000/50
		Protection Level /Insulation Level		IP55/F
13	Fan	Power	kW	3.5×2
		Voltage/frequency	V/Hz	380/50
		Speed	rpm	1440
		Air volume	m3/h	20000×2
14	Dimensions		mm	2800*1560*1920
15	Weight		kg	4500
16	Export size		flange	DN100

Unicol single-stage
permanent magnet variable frequency screw air compressor
main configuration table

NO	Item	Brand	Country/region
1	Oil-gas separator filter element	UNICOL	UNICOL
2	Air filter	UNICOL	UNICOL
3	oil filter	UNICOL	UNICOL
4	inlet valv	E-GATE	Zhejiang
5	Compressor air end	UNICOL	UNICOL
6	Oil and gas separation tank	JuCai	China
7	cooler	UNICOL	UNICOL
8	temperature sensor	OLD	Shenzhen
9	pressure sensor	OLD	Shenzhen
10	solenoid valve	Intake valve integrated	ZheJiang
11	safety valve	ChaoChao	ZheJiang
12	thermostat valve	E-GATE	ZheJiang
13	proportional valve	E-GATE	ZheJiang
14	air release valve	E-GATE	ZheJiang
15	coupling	JICHAO	ZheJiang
16	control circuit apparatus	Siemens	Germany
17	PLC	Mushroom iot	Shenzhen
18	permanent magnet motor	Jiangtian	ZheJiang
19	box	UNICOL	UNICOL
20	Base	UNICOL	UNICOL
21	Inverter	INVT	Shenzhen
22	Fan	UNICOL	UNICOL
23	cooling liquid	UNICOL	UNICOL

---
