Self-Adhesive Paper Kraft Paper Slitting Machine Automatic Paper Roll Rewinding Slitter Machine

US$13,000.00-26,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
KTSM-H200
Type
Coil Paper Slitting Machine
Work Method
Round Knife Cutting
Structure
Cutting Part
Packaging
Cartons
Classification
Paper Slitting Rewinding Machine
Applicable Process
Process Materials
Suitable Substrates
Paper
Packaging Material
Wood
Product Name
Paper Slitting Machine
Keyword
Plastic Film Slitting and Rewinding Machine
Keyword 1
Nonwoven Slitting Machine
Keyword 2
Paper Slitter Rewinder Machine
Keyword 3
Slitting Machine for Non-Woven
Keyword 4
Non Woven Slitter
Keyword 5
Automatic Slitting Machine
Keyword 6
Automatic Paper Roll Rewinding Slitter Machine
Paper Slitting
Yes
Non Woven Fabric Slittin
Yes
Round Slitting Knife
Yes
Roll to Roll Slitting
Yes
Unwind with Air Shaft
Yes
Rewind with Air Shaft
Yes
Unwind with Auto Loading
Yes
Transport Package
Wooden Pallet
Specification
2800x1800x1400mm
Trademark
KETE
Origin
China
Production Capacity
20 Sets/ Month

Packaging & Delivery

Package Size
280.00cm * 180.00cm * 140.00cm
Package Gross Weight
2500.000kg

Product Description


This Paper Slitting Rewinding Machine Is Suitable for Slitting Roll Type Materials, Such As Paper, Plastic Film, Non Woven Fabric, Etc. Ω Use Round Slitting Knife.
Ω With Auto Length Counting System.
Ω Unwind and Rewind with Tension Control.
Ω Unwind with EPC Control System.
Ω Unwind and Rewind using Air Shaft. Ω Inverter uses Import Brand. Ω Electrical Parts use Schneider Brand.
Ω Optional: Unwind Shaft Type Auto Loading.
Ω Optional: Unwind Shaft-less with Auto loading.
Ω Optional: Straight Slitting Knife.
Model KTSM-H200/ 1100 KTSM-H200/ 1300
Max. Raw Material Width 1000mm (39.4") 1200mm (47.2")
Max. Unwind Diameter Φ800mm (31.5") Φ800mm (31.5")
Max. Rewind Diameter Φ450mm (17.7") Φ450mm (17.7")
Min. Slitting Width 50mm (1.97") 50mm (1.97")
Max. Slitting Speed 200m/min 200m/min
Error <0.5mm <0.5mm
Paper Core Inner Diameter 76mm/152mm (3"/6") 76mm/152mm (3"/6")
Total Power 4.5kw 5.5kw
Machine Weight 2200kg 2500kg
Machine Size (LWH) 2800 x 1600 x 1400mm 2800 x 1800 x 1400mm
Machine Power 3 Phase 220 / 380 / 440v 50/60Hz
