Product attributesProperty valueSelect Properties
| Manufacturer: | Texas Instruments |
|
| Product Category: | Analog comparator |
|
| RoHS: | Details |
|
| Installation style: | SMD/SMT |
|
| Package / Enclosure: | SOIC-14 |
|
| Number of channels: | 2 Channel |
|
| Output Type: | Open Collector |
|
| Response time: | 80 ns |
|
| Comparator type: | General Purpose |
|
| Supply Voltage - Min: | 5 V |
|
| Supply Voltage - Max: | 36 V |
|
| Operating supply current: | 4.3 mA |
|
| VOS - Input Bias Voltage : | 8 mV |
|
| IB - Input bias: | 1 uA |
|
| Minimum operating temperature: | 0 C |
|
| Maximum operating temperature: | + 70 C |
|
| Series: | LM319-N |
|
| Encapsulation: | Reel |
|
| Encapsulation: | Cut Tape |
|
| Encapsulation: | MouseReel |
|
| Trademark: | Texas Instruments |
|
| Dual supply voltage: | +/- 15 V |
|
| GBP-Gain Bandwidth Products: | - |
|
| Height: | 1.45 mm |
|
| Input Type: | Differential |
|
| IOS - Input Bias Current : | 200 nA |
|
| Length: | 8.64 mm |
|
| Maximum dual supply voltage: | +/- 18 V |
|
| Minimum dual supply voltage: | +/- 2.5 V |
|
| Operating supply voltage: | 9 V, 12 V, 15 V, 18 V, 24 V, 28 V |
|
| PD-Power Dissipation: | 500 mW |
|
| Products: | Analog Comparators |
|
| Product Type: | Analog Comparators |
|
| Shut down: | No Shutdown |
|
| Factory packing quantity: | 2500 |
|
| Subcategories: | Amplifier ICs |
|
| Power supply type: | Single, Dual |
|
| Technology: | Bipolar |
|
| Type: | High Speed Comparator |
|
| Voltage gain dB: | 92.04 dB |
|
| Width: | 3.91 mm |
|
| Unit weight: | 241 mg |
|
