| ENGINE | |
| Model | XINCHAI A495BG / YANMER 4TNV88 |
| Cylinders | 4 |
| Bore/Stroke | 95×105mm |
| Displacement | 2.977L |
| Fuel injection | direct |
| Fuel injection pump | Mechanical |
| Fuel | Diesel |
| Fuel filter | Full flow |
| Cooling | water-cooling |
| Horswpower(net) | 30kw @2200rpm |
| Maximum torque(net) | 165N.m @1650rpm |
| BOOM/ARM | |
| Boom | |
| Swing | 75° left / 45° right |
| Length | 2745mm |
| Boom weight | 180kg |
| Arm | |
| Length | 1600mm |
| Arm weight | 80kg |
| UNDERCARRIAGE | |
| Number of rollers | |
| Top,each track | 1 |
| Bottom,each track | 4 |
| Gradability | 58%(30°) |
| HYDRAULICS | |
| Pumps(3) | 2×Variable displacement piston pump+gear pump |
| Capacity- Maximum | 2×45L/min+36L/min |
| System relief pressure- | |
| Standard | 24.5MPa+20.6MPa |
| Pilot control hydraulic system- | |
| Pumps(1) | Gear pump |
| Maximum capacity | 10.7L/min |
| Relief pressure | 3.5MPa |
| Control valves- | |
| 8 function multiple control valve | |
| Pump #1 for right travel and boom function and bucket function |
| Pump #2 for left travel and arm function |
| Pump #3 for house swing and dozer function and boom swing |
| Pump #4 for pilot valve | |
| Swing- | |
| Motor(1) | Fixed displacement axial piston design |
| Speed | 0-12.5rpm |
| Brake | Spring applied,hydraulically released with dual cushion relief |
| Tail swing radius | 1630mm |
| Travel- | |
| Motor(2) | Two-speed axial piston design |
| Final drive | Planetary gear reduction |
| Travel speeds- | Forward/Reverse |
| Low | 2.5km/h |
| High | 4.5km/h |
| HYDRAULIC CYLINDERS | |
| Boom cylinder(1) | |
| Bore diameter | 90mm |
| Rod diameter | 45mm |
| Stroke | 535mm |
| Arm cylinder(1) | |
| Bore diameter | 90mm |
| Rod diameter | 45mm |
| Stroke | 600mm |
| Bucket cylinder(1) | |
| Bore diameter | 80mm |
| Rod diameter | 45mm |
| Stroke | 600mm |
| ELECTRICAL | |
| Voltage | 12 volts |
| Alternator | 40 amp |
| Batteries(1) 12V | Heavy-duty |
| SERVICE CAPACITIES | |
| Hydraulic tank | |
| Refill capacity | 80L |
| Total system | 100L |
| Engine | |
| w/filter change | 6.5L |
| Fuel | 70L |
| Radiator | 6L |
| OPERATING WEIGHT | |
| With 75kg operator | 4000kg |
| Ground pressure | 33KPa |
