| US$377.00 | 1 Piece (MOQ) |
| Mechanical technical literatures | Mainboard | IFG41 full-size card |
| Processor | Intel E6300(pentium Dual-core 2.8GHz) | |
| Chipset | Intel G41+ICH7R | |
| Memory | 2G DDR3,MAX:4GB | |
| Memorizer | 500G SATA 3.5 inch HDD | |
| CD-ROM | Asus DVD CD-ROM(Optional) | |
| Keyboard mouse | A4TECH USB Keyboard and mouse(Optional) | |
| Power supply | FSP300W AC 100-240V | |
| Display | VGA | 1*VGA |
| I/O Interface | COM | 2* Serial port(COM2 support RS232/422/485) |
| LPT | 1*LPT port | |
| USB | 4*USB2.0,Max 8*USB2.0 | |
| Network | 2*1000Mbps(RTL8111DL) | |
| Expansion Interface | PCI | 4*PCI slot |
| ISA | 8*ISA slot | |
| PCI-E | -- | |
| -- | ||
| Case size | 480 x 427x 177 mm(DxWxH) | |
| Pack size | 610 x 520x 260 mm(DxWxH) | |
| Operating temperature | -20ºC~60ºC 10~90%@40ºC(Non self-solidifying) | |
| Storage temperature | -40~70ºC 5%~90%@40ºC(Non self-solidifying) | |
| TYPE | configuration list | |||||||
| PICMG | CPU | Memory | Power supply | CD-ROM | Memorizer | Mainboard | 4U Case | |
| YR-IPC610C-G31 | PICMG1.3 | E5300 | DDR2 -2G | FSP300W | / | 500GSATAHDD | IFG31 | IPC-610H |
| YR-IPC610C-865 | PICMG1.0 | P4 2.8G | DDR-1G | FSP300W | / | 80G IDE HDD | IF865 | IPC-610H |
| YR-IPC610C-815 | PICMG1.0 | Celeron1G or PIII 1G | SD256M or 512M | FSP300W | / | 80G IDE HDD | IF815 | IPC-610H |
