Wonergy Solardachziegel BIPV Solar Power Roof System Solar Roof Tile

Product Description

Specifications

PHYSICAL FEATURES
MODEL	JS87DG	TILE SIZE	1260*480 MM
TILE WEIGHT	16.5 KG	GLASS	TEMPERED/3.2MM
CELL SIZE	182*91MM(5*12)	JUNCTION BOX	≥ IP67
CABLE	PV 4 MM2	CABLE CONNECTOR	MC4
ELECTRICAL PERFORMANCE PARAMETERS (IN STC)
CELL TYPE	MONOCRYSTALLINE	CELL EFFICIENCY	23.10%
MAX POWER90	90W/PC	MODULE EFFICIENCY	18.40%
VOLTAGE	13.7V	CURRENT	6.35A
OPEN-CIRCUIT VOLTAGE	16.2V	SHORT-CIRCUIT CURRENT	6.75A
RATING FEATURES
COLOR	BLACK + CUSTOMIZABLE	LOAD CLASS	2400 PA
FIRE-PROOF CLASS	CLASS A	HAIL-RESISTANT CLASS	25MM/23M/S
WORKING TEMP	-40ºC ~ 85ºC	WORKING HUMIDITY	0-80%
CERTIFICATIONS
TUV, CGC, MCS, SII, BIS, INMETRO, SNI, CEC, JET, CARBON FOOTPRINT, etc.

Benefits
More Models Are Available
How Solar Roof Works?
How Does A Solar Roof Work And How Can It Benefit Your Family? Nowadays solar energy is becoming much more popular and common in our life, and you might have seen some of your neighbors' houses covered with solar roof tiles. Let us make a brief explanation of how it works to you here: *1)* Sunlight hits the solar cells to get the power, then the energy is converted to DC electricity. *2)* The electricity goes to the inverter and is converted into AC electricity that runs the home appliances. *3)* The excess power produced can be sold to the utility through net metering to reduce bills or make money. *4)* Also the excess electricity can flow through the inverter to change back into DC electricity that can be stored for later use. *5)* If the house needs to use the energy stored in the battery, that electricity will flow through the inverter again to become AC electricity. *6)* A mobile monitoring app will show how much electricity the solar roof system is creating and your home is using, and the savings you're generating. In the coming years, solar roofs will become quite common with the urging need for clean energy. And people will not just be satisfied with the traditional solar panels that are mounted on the roof. What people will favor is a solar roof that combines the functions of power generation and home protection.
Solar Tile v.s Solar Panel
Solar panels are well-known by many people. But solar roof tiles are relatively new to most customers. So we made this video to make a brief analysis of the differences between solar panels and solar tiles. The video analyses the below four aspects: 00:30 Installation
01:30 Aesthetics
02:00 Durability
02:25 Cost
P.S.: Kindly chat with us to get the full video link
It Is Good For You If
YOU ARE PASSIONATE ABOUT DESIGN
The appearance of your roof is important to you. You want to make use of solar energy but don't want regular solar panels on the roof. Sangobuild solar roof offers a neat, sleek look and the solar cells are almost invisible in a distance.
YOU ARE RENOVATING OR BUILDING A NEW ROOF
If you are renovating or about to change your roof, you may want save on material and labor costs. A Sangobuild solar roof gives you both roofing material and powerful solar panel in one.
IF YOUR BUILDING IS LISTED
If your building is listed as being of historical or architectural significance, you may not be able to install standard type of solar panels on your roof. Sangobuild solar roof, on the other hand, is usually accepted by the authorities because it looks like a conventional roof. Why Choose Us?
IT'S A ROOFING MATERIAL!
Sangobuild Solar Roof Tile is a kind of roofing material just like conventional roof tiles. It not only can generate electricity power, but also can work as your roof cover to protect your house from rain, wind, hail, etc. It saves your roofing cost. You don't need to install any traditional roofing materials. And you don't need to set up mounting racks on the roof to install solar tiles, which could affect the roof's beauty to some extent.
EXCELLENT PRODUCT FEATURES
As a Building-Integrated Photovoltaic solar roof tile, our product not only has great electricity power generation features, but also has excellent weathering resistant features.
- High efficient whole roof covering
- Class A waterproofing
- Hail Resistant
- Wind Resistant
- More than 60 years lifespan
- Aesthetically Appealing
PROFESSIONAL TEAM
Our team started the business of Building-Integrated Photovoltaic in 2007, and is leading the technology in the industry. We not only has the most professional team for solar energy, but also has the most professional team for roofing.
We combines the solar panel and the roof tile and make it a new product to save the cost and make your roof more beautiful and functional! Send Us An Inquiry And Let's Empower Your Roof!

---
