At Zhejiang Shengjiang Machinery Co., Ltd. We understand the importance of precision, reliability, and efficiency in blow molding operations. That′s why we have invested in state-of-the-art manufacturing facilities and assembled a team of experienced professionals dedicated to delivering superior products and services. Our product lineup includes a wide range of blow molding machines, including: Extrusion blow molding machines Stretch blow molding machines Multi-layer blow molding machines
| CODE | SYJ1-65-8 |
| Maximum product capacity | 330ml |
| Output (PCS/hour) | 2000(330ml) |
| Voltage and frequency converter | 380V/50HZ |
| Screw diameter (mm) | 65 |
| Screw length-diameter ratio | 1:25 |
| Screw speed (r/min) | 10~90 |
| Screw material | 38CrMOAlA |
| HDPE extrusion capacity (kg/h) | 75 |
| Modular number | 1 |
| Die head heating section | 1 |
| Die head heating rate (KW) | 1.7 |
| Screw heating section | 3 |
| Screw heating rate (KW) | 10.5 |
| Extrusion motor attack rate (KW) | 15 |
| Stroke rate of Rotary motor (KW) | 1.5 |
| Total installed attack rate (KW) | 28.5 |
| Extruder size (L X W X H) | 2.5mX0.8mX2.03m |
| Rotating machine dimensions (L X W X H) | 2.0mX1.8mX1.38m |
| Theoretical weight of extruder (KG) | 700 |
| Theoretical weight of rotary machine (KG) | 1000 |
| Average energy consumption (KW/h) | 16 |
| Average energy consumption (water m3/h) | 2 |
| Average energy consumption (gas m3/min) | 2.5 |
