Basic Info.
Separation Mode
Sedimentation Type
Operating Type
Intermittent Type
Centrifuge Type
Tube Centrifuge
Showroom Location
Canada & Britain & America & Germany
Transport Package
Standard Exporting Packing
Specification
450× 760× 1120
Production Capacity
500 Sets Per Year
Product Description
GQ Tubular Centrifuge
High speed separation & clarification. GQ series Tubular Centrifuge from Huading Separator is a high speed solid bowl type machine for continuous removing solids from liquid with density difference.
Tubular centrifuge is an ideal instrument in biology, traditional medicine preparation, health food, chemistry for liquid-solids separation. It is especially designed for separation and clarification of process liquid with low density difference, small granularity, low solid content, strong medium corrosion.
| |
| Transfer drum | Nozzle diameter
(mm) | Capacity
(Through water)
(kg/h) | Motor Power
(kw) | Weight
(kg) |
| Model | Diameter
(mm) | Height
(mm) | Volume
(L) | Speed
(r/min) | Separation factor
|
| GQ45 | 45 | 280 | 0.45 | 50000 | 60000 | 2,3 | 150 | 0.75 | 90 |
| GQ75 | 75 | 450 | 2.7 | 21000 | 22500 | 4,6 | 500 | 1.5 | 300 |
| GQ105 | 105 | 730 | 6 | 19000 | 21000 | 6,8 | 1500 | 2.2 | 480 |
| GQ125 | 125 | 730 | 7.4 | 16000 | 18000 | 5,8,9 | 2000 | 3.0 | 520 |
| GQ137 | 137 | 730 | 9 | 15000 | 17000 | 6,8,10 | 3000 | 3.0 | 550 |
| GQ150 | 142 | 730 | 10 | 15000 | 17000 | 8,10,12 | 3000 | 3.0 | 550 |
>>
