Metal Coil Automatic Stamping Press Servo Feeder Cut to Length Line Shearing Machine

Product Description

Product Description
Features of Uncoiled, Straighter and Feeder 3 in 1
1. Suitable all kinds of metal sheet straightening and feeding
2.Suitable for metal parts,electron,electrical appliance, toy and auto parts continuous pressing production,straightening and feeding.
3. Servo motor of this machine,electrical box and ome other parts are from Japan, with less malfunction and long using time.
4. Chrome plate,high precision,more durable.
5. Input feeding length, easy operation, safe and high stability.
Straightening capacity diagram
1.This diagram is suitable for condition,which material stretch intensity is 40kgf/ mm.
2. Straightening capacity may be change because of different actual condition.
3. About coil outer diameter,material widthand deciliter standard load weight,pleaserefer to deciliter attachment diagram ofthis catalogue.
4. About particular specification manufacturing, please contact us.

Specification

	Model	NCMF-300	NCMF-400	NCMF-500	NCMF-600
Ltem
Material thickness		0.4-2.5(Straighteningrollerl49x5up/5down)
Material width	mm	300	400	500	600
Coil Inner diameter	mm	ф450~Ф530	ф450~Ф530	ф450~Ф530	ф450~Ф530
Coilouter diameter	mm	Ф1400	Ф1400	Ф1400	Ф1400
Coil weight	kg	3000	3000	5000	5000
Decoiler power	HP	2.2	2.2	3.7	3.7
Straightening power	kw	2	2	3.5	3.5
Expansion style		Hydraulic expansion	Hydraulic expansion	Hydraulic expansion	Hydraulic expansion
Size	m	4.5x1.5x2.3	4.5x1.7x2.3	4.5x1.9x2.3	4.5x2.0x2.3
Weight	kg	~2200	~2400	~2800	~3000

	Model	NCGK-500	NCGK-800	NCGK-1000	NCGK-1300
Ltem
Material thickness		1.5-8.0(Straighteningrollerl84x5up/5down)
Material width	mm	500	800	1000	1300
Coil Inner diameter	mm	ф450~Ф530	ф450~Ф530	ф450~Ф530	ф450~Ф530
Coilouter diameter	mm	Ф1400	Ф1400	Ф1400	Ф1400
Coil weight	kg	5000	5000	7000	7000
Decoiler power	HP	2.2	2.2	3.7	3.7
Straightening power	kw	5.5	5.5	7.5	11
Expansion style		Hydraulic expansion	Hydraulic expansion	Hydraulic expansion	Hydraulic expansion

Item	Model	NCBF-400	NCBF-500	NCBF-600	NCBF-700	NCBF-800	NCBF-1000
Material thickness		0.5-6.0(Straighteningrollerl68x4up/3down)
Material width	mm	400	500	600	700	800	1000
Coil Inner diameter	mm	ф450~Ф530	ф450~Ф530	ф450~Ф530	ф450~Ф530	ф450~Ф530	ф450~Ф530
Coilouter diameter	mm	Ф1500	Ф1500	Ф1500	Ф1500	Ф1500	Ф1500
Coil weight	kg	2000	3000	5000	5000	5000	5000
Decoiler power	HP	2.2	2.2	3.7	3.7	5.5	5.5
Straightening power	kw	4.4	4.4	5.5	5.5	5.5	7.5
Expansion style		Hydraulic expansion	Hydraulic expansion	Hydraulic expansion	Hydraulic expansion	Hydraulic expansion	Hydraulic expansion
Size	m	4.5x1.9x1.8	4.5x2.0x1.8	4.5x2.1x1.8	4.5x2.3x1.8	4.5x2.5x1.8	4.5x2.8x1.8
Weight	kg	~3200	~3900	~4800	~5100	~5600	~6200
