Factory Supply Directly 24ton Wheel Excavator with Front Dozer Blade and Rear Outrigge

Product Description

Product Description

1. Hybrid type scap handling manipulator of China,Low working cost:
Hybrid type design with both diesel engine and electricity power motor will lower the customer's using cost. Diesel engine will make equipment movable easily. When the machine working in fixed site, it can only use electricity, which will lower the using cost and lengthen the lifetime of the equipment.
2.Very good movable advantage.
Wheeled type make the machine movable and no need for extra trailer to transport it.
3.More efficient than crane.
Normal crane can not grab some special materials such as scrap. ForSL924C, it adopts specially designed foldable booms and can handle special materials such as scrap. It can also be used for loose reed grass, wood, bamboo, paper, soil, sand, stone and other equipment for optimal handling, stacking and unstacking operations.
4. Patented hybrid design,
diesel engine and electricity can be exchangeable quickly. Normal 380V electric mode will save 60% of energy than diesel engine. 440/460 motor is optional.
Patented hybrid design. Double power can be switched very easily and safely.
For Electric mode, there are safety control system such as protection devices for overcurrent, overload, overheating, earth leakage.
Equipped with Y / buck starting devices;
Automatic Identification phase sequence to prevent the pump reversing;
The hydraulic system can automatically cut off electricity and oil, starts self-locking, self-protective for emergency situation ;
There are a number of complex action operations, improving work efficiency;
The hydraulic system is installed with air-cooled radiator;
Gripper 360 degree rotated;
A/C for upper cabin;
Hydraulic controlled lifting cab, very widely and clear view
Product Parameters

Type	Items					Unit	Parameter
Performance parameters	Max. Lifting Weight					kg	10000
	Working Range (Max.Lifting Weight)					mm	3000
	Max. Working Range					mm	10200
	Lifting Weight (Max.Working Range)					kg	2500
	Max.Lifting Moment					kN.m	300
	Max. Lifting Height					mm	11300
	Legs stabilizers distance				Longitudinally	mm	4500
					Transverse	mm	4200
Main Working Time	Main Luffing Action Time (Max.speed)	Lowing arm time		Drive Type	Motor	s	≤17.0
					Engine	s	≤15.0
		Lifting arm time			Motor	s	≤18.0
					Engine	s	≤16.0
	Max.swing speed				Motor	r/min	≥9.0
					Engine	r/min	≥10.0
	Vice Luffing time (Max.Speed)		Lifting arm		Motor	s	≤14.0
					Engine	s	≤13.0
			Lowing arm		Motor	s	≤10.0
					Engine	s	≤10.0
	Retractable Legs Time		Open meantime		Motor	s	≤16.0
					Engine	s	≤15.0
			Close meantime		Motor	s	≤11.0
					Engine	s	≤10.0

Type	Items		Unit	Parameter
Overall Dimension	Overall Length		mm	10900
	Overall Width		mm	2990
	Overall Height		mm	3440
Tire Tread	Front Tire		mm	2350
	Rear Tire		mm	2090
Wheel Base			mm	2800
Power Parameter	Max. Motor Power		kW	75
	Max. Engine Power		kW	199
Parameter	Weight in traveling		kg	23000
	Axle Load	steering shaft load	kg	7500
		Drive Shaft load	kg	15500
Traveling Parameter	Max.Speed		km/h	15
	Min.Turning Radius		m	13
	Max.Grade Ability		%	10
	Min.Ground Clearance		mm	250
	Approach angle		°	15
	Departure angle		°	15
	Braking distance		mm	≤6500
Noise limits	Radiation outside machine		dB(A)	≤118
	Position driver		dB(A)	≤90

Detailed Photos

Cummin-s 6BTAA5.6 6 Cylinder Engine
133KW
KAWASAKI PUMP
EATON MOTOR
SUITABLE CABIN
TRANSMMSION
OPERATION SEAT
Our Advantages

Packaging & Shipping

---
