| Product model | QA-500 | ||
| Engine | Honda/CHANGFA | vibration force | 30kn |
| Engine type | Gx270/178F | Amplitude | 0.6mm |
| Power | 6.6kw/4kw | Vibration Frequency | 75HZ |
| fuel consumption | 363g/kw/h | Climbing angles | <30° |
| Lubricating oil quantity | 1.1L | Walking speed | 1.2-2.8km/h |
| Hydraulic pressure oil mass | 15L | Diameter of steel wheel | 560mm |
| tank capacity | 40L | Width of the steel wheel | 700mm |
| Drive way | Hydraulic motor | Supporting wheel size | 140*365mm |
| working | Go forward and backward | weight | 500kg |
| vibration mode | Manual clutch/Electric clutch | Packing size | 125*85*135cm |
