Plastic Children Chair Manufacturing Injection Molder

Product Description

China Servo Injection Molding Machine
Ningbo Union Power Machinery Co., Ltd.
Product Description:
Modulus of Capacitance: Includes position, size, maximum allowable modulus of capacitance, and minimum closure thickness of the injection molding machine guide pillar (Green column).
Nozzle Parameters: Specifies spherical diameter, aperture, outer diameter, maximum extension length, and positioning aperture of the nozzle.
Code Mold Parameters: Covers mold hole and slot size for code molding.
Ejection Mechanism: Details ejection point position, ejector rod diameter, and optional ejection force and stroke.
Mold Opening Stroke: Indicates mold opening stroke and maximum opening distance.

Technical Parameters	Model UP-420T
Injection Unit	A	B	C
Screw diameter (mm)	70	75	80
Shot Volume (cm3)	1385	1590	1810
Injection weight (g)	1247	1431	1628
injection pressure (Mpa)	199	173	152
Screw speed (rmp)	230
Clamping Unit
Clamping force (KN)	4200
Open stroke (mm)	740
Max Mold height (mm)	750
Min Mold height (mm)	280
Space between tie bars(mm)	745x745
Ejector force (KN)	110
Ejector stroke (mm)	180
Others
Pump pressure (Mpa)	16
Motor/driving power (KW)	39.7
Heating power (KW)	29
Machine dimension (M)	7.35x1.95x2.4
Machine weight (T)	15.4
Oiltank cubage (L)	650

---
