project
| parameter
| project
| parameter
|
Card reader type
| EM card or M1 card
| Barcode type
| QR, one/two-dimensional code
|
communication method
| Wiegand 26/34/RS232/RS485/TTL
| Decoding mode
| Image decoding
|
Reading direction (bar code)
| Angle 45° with the lens as the center point
| Scan code characteristics
| Automatic induction, buzzer prompt
|
Operating Voltage
| 8-12V
| Working current
| 800mA
|
Card reading distance (card)
| 3~6CM
| Reading speed
| ＜200ms
|
Reading distance (QR code)
| 0-20cm
| Material quality
| Zinc alloy frame + acrylic panel
|
Working humidity
| 10%~90%
| Operating temperature
| -20℃~70℃
|
operating system
| WindowsXP/7/8/10), Linux
| Size
| 86mm×86mm×18mm
|
Indicator light
| Blue work light, green feedback light
| Weight
| 150G
|
other
| Light: Standby state: blue light is always on; card reading/scan code state: green light is on for about 0.5s
Built-in horn: buzzer
|
