| US$6,400.00-7,000.00 | 1 Piece (MOQ) |
| ITEM | UNIT | T32 | |
| General Rules | CNC system | GSK | |
| physical dimension | mm | 1900*1500*1680 | |
| Total weight of machine tool | kg | 1600 | |
| Bed type | 30° inclined bed | ||
| The scope of work | Maximum rotation diameter on the bed | mm | φ360 |
| Maximum rotation diameter on the pallet | mm | φ120 | |
| X-axis maximum travel | mm | 680 | |
| Z axis maximum travel | mm | 400 | |
| Spindle | Spindle | Mechanical spindle | |
| Spindle speed | rpm | 50-3000 | |
| Spindle end | A2-5 | ||
| Spindle through hole diameter | mm | φ48 | |
| Working accuracy | Servo main motor power | kw | 4 |
| X-axis servo motor | Nm | 4 | |
| Z-axis servo motor | Nm | ||
| X-axis guide rail type | Linear Guides | ||
| Z-axis guide rail type | Linear Guides | ||
| X-axis fast forward speed | m/min | 18 | |
| Z-axis fast forward speed | m/min | 20 | |
| Tool holder | Tool holder form | Row knife | |
| Number of tool positions | 4 | ||
| Knife square size | mm | 20*20 | |
| other | Clamping method | Hydraulic clamping | |
| Cylinder Specifications | Hydraulic hollow 536 | ||
| Hydraulic station | Shengquan high performance hydraulic station | ||
