| Model | GZN1-15000-24 | GZN1-15000-36 | GZN1-15000-48 | GZN1-15000-60 | GZN1-15000-110 | GZN1-15000-220 | ||
| O U T P U T | DC voltage | 24V | 36V | 48V | 60V | 110V | 220V | |
| Rated current | 625A | 416A | 312A | 250A | 136A | 68A | ||
| Current range | 0 - 6 2 5 A | 0 - 416A | 0 - 312A | 0 - 250A | 0 - 136A | 0 - 68A | ||
| Rated power | 15000W | |||||||
| Ripple & Roise | 500mV | 500mV | 600mV | 600mV | 1000mV | 1500mV | ||
| Constant current range | 12 - 24V | 18 - 36V | 24 - 48V | 30 - 60V | 55 - 110V | 110 - 220V | ||
| Voltage tolerance | ±1.0% | |||||||
| Line regulation | ±1.0% | |||||||
| Load regulation | ±1.0% | |||||||
| Setup risetime | 1500mS ,700mS/ 230VAC( Full load) | |||||||
| I N P U T | Voltage range | 95- 190 VAC(output current 50%) , 195- 265 VAC(output current 10 0%) | ||||||
| Frequency range | 45Hz - 65Hz | |||||||
| Power factor | PF>=0 .99/ 230VAC( Full load) | |||||||
| Efficiency( MAX) | 90 % | 91.5 % | 92 % | 92 % | 92.5 % | 93 % | ||
| AC Current | <110A | |||||||
| Leakage current | <3 .0mA / 240VAC | |||||||
| PROTECTION | Short curcuit | Enter the constant current and the voltage is less than 10% of the rated voltage, turn off and lock the output after 1 second, and resume after restart | ||||||
| Over current | The user can set a delay of 5 seconds after the current value is turned off, and the output can be restored after restart | |||||||
| Over voltage | The user can set the overvoltage value to turn off the output voltage, and resume after restart | |||||||
| Over temperature | Turn off the output and automatically recover or restart after the temperature drops | |||||||
| FUN CTI ON | Output voltage adjustment | 0 - 26.4V | 0 - 39.6V | 0 - 52.8V | 0 - 66V | 0 - 121V | 0 - 242V | |
| Output constant current adjustment | 0 - 740A | 0 - 500A | 0 - 375A | 0 - 300A | 0 - 163.6A | 0 - 81.8A | ||
| 485 communication | MODBUS Communication protocol | |||||||
| Isolating auxiliary power supply | 12V 0.5A ( Need to be customized) | |||||||
| Output remote control switch | Default power on, high power off(5V-12V) ( Need to be customized) | |||||||
| Alarm output | Power normal signal ( Dry contact <= 36 V , 0 . 1A )( Need to be customized) | |||||||
| ENV IRO NM ENT | Working TEMP. | -20 - +60ºC | ||||||
| Working humidity | -20 - 90% RHnon-condensing | |||||||
| Storage TEMP. and humidity | -40 - +85ºC, 10 - 95% RH non-condensing | |||||||
| Vibration | 10 - 500Hz, 2G 10mins/T, X ,Y ,Zaxis 60 minutes each | |||||||
| SAF ETY & E MC | Isolation resistance | Input-output: 100 Mhms/500 VDC/ 25 ºC/70% RH | ||||||
| Withstand voltage | I/ P-O/ P : 2KVAC I/ P- FG:2KVAC O/ P- FG:0 . 5KVAC | |||||||
| OTH ERS | Dimension | 455 *345 * 251mm(L*W * H) | ||||||
| Net weight | 22 KG | |||||||
| Remark | 1 . All parameters NOT specially mentioned are measured at 23 0 VAC input, rated load and 25 ºC of ambient temperature. 2 . Ripple &noise are measured at 20 MHz of bandwidth by using a 12 " twisted pair-wire terminated with a 0 . 1uf &47uf parallel capacitor. 3. Tolerance: includes set up tolerance, line regulation and load regulation. 4. If the input voltage is low, the output needs to be derated. For details, see the static characteristic diagram. 5. Length of setup time is measured at cold first start,Turning ON/OFF the power supply may lead to increase of the setup time. | |||||||
