| US$28,000.00-480,000.00 | 1 Set (MOQ) |
| Oil yied/day | Waste tire/ rubber | Big tyres | 45%--50% |
| Car tyres | 40% | ||
| Bicycles and motorcycles tyres | 30%--35% | ||
| Waste plastic | Fishing net | 45%--50% | |
| Safety net , farm-oriented film | |||
| Conwenient bags , weave bags | 40% | ||
| Off cut of recycled paper mill | 20%--30% |
| 1.Reactor |
| 2.Catalyst tower |
| 3.Oil separator |
| 4.Condenser cooling system |
| 5.Cooling pool |
| 6.Light oil collection tank |
| 7.Heavy oil collection tank |
| 8.Vacuum system |
| 9.Water seal tank |
| 10.Dust remove disposal device(strong spray tower,draft fan,active carbon absorption tower,purify water pool) |
| 11.Operation plat form |
| 12.Power Control cabinet |
| 13.Other accessory |
| NO. | Name | Parameter |
| 1 | The raw materials: | waste tyres, plastic and oil sludge,rubber |
| 2 | Total capacity: | 10t/day |
| 3 | The size of reactor | 2800*6000mm, |
| 4 | Average oil productivity: | tyre:40%-50%, plastic:60%-80% |
| 5 | Average carbon productivity: | 30%-35% |
| 6 | Average steel productivity: | 10%-15% |
| 7 | Average waste-gas productivity: | 5-8% |
| 8 | pyrolysis time | 8hours |
| 9 | Discharge time | 3hours |
| 10 | Feeding time | 3hour |
| 11 | Cooling time | 3hours |
| 12. | Delivery | 15 days |
| 13. | Payment term | 30% Advance payment, balance paid before plant loading |
| 14. | Oversea users | Lebanon,Korea,Poland,Turkey,Mauritius,Brazil,Malaysia, Indonesia,Vietnam,Philippine,Thailand,Pakistan,India |
| 15. | Installation | Engineer guiding installation for free,buyers offer round-tickets and accommodation |
| 16. | Warranty period | 2 years warranty, lifetime maintenance |
| Specification | Capacity | Raw material | Heating material | Working time (hrs) | Shipped by |
| XHZT-2200-6000 | 5Ton | Waste tyres Cables Plastics Rubber Oil sludge | Wood,coal ,oil,gas | 12 | 2*40HQ |
| XHZT -2600-6000 | 8Ton | 15 | 1*40HQ+1*40FR | ||
| XHZT -2600-6600 | 10Ton | 18 | 1*40HQ+1*40FR | ||
| XHZT -2800-6000 | 10Ton | 18 | 1*40HQ+1*40FR | ||
| XHZT -2800-6600 | 12Ton | 20 | 1*40HQ+1*40FR | ||
| XHZT -2800-6600 | 15ton | Medical waste | 22 | 1*40HQ+1*40FR | |
| Contiuous plant | 20Ton | Other waste | 24 | 3*40HQ | |
| Contiuous plant | 60Ton | 24 | 5*40HQ |
| Density | g/cm3 | 0.83-0.87 |
| Freezing Point | oC | 10 |
| flash point | oC | 40 |
| Kinematic viscosity | mPa.s | 8 |
| Combustion value | kJ/kg | 9500 |
