HC-C008 Hot Sale 12.1 inch CTG Fetal Doppler Monitor/ Doppler fetal monitor

Product Description

Product Description
HC-C008 Hot Sale 12.1 inch CTG Fetal Doppler Monitor/ Doppler fetal monitor
Product Description
Features for HC-C008 Hot Sale 12.1 inch CTG Fetal Doppler Monitor/ Doppler fetal monitor:

HC-C008, is a high-end fetal monitor, and it offers the most advanced integrated monitoring for the delivery room in big hospital; private obstetrician's office; antepartum clinic. They are designed for use in moving situation covers the entire continuum of antepartum and intrapartum applications.

Features
Light weight, space-saving, easy operation
Interface of parameters of FHR, TOCO, FM with digital and curve display
Special high sensitive water proof probe
Built-in 152mm long life thermal printer, the life exceeds over 20 years.
Advanced technology, realtime identify and measurement for FHR, accurate and reliable results
Battery indication, pregnant No. Display
12 inch TFT color screen folding up to 90 degree
Multi-crystals, wide beam form high sensitivity ultrasound transducer, 1MHz pulsed wave, low ultrasound power, safer to the fetus
24 hours data storage which can be playback and printed
Wide range of applying voltage (100-240 V)
Manual / automatic fetal movement detection
3 in 1 transducers, avoid twisting.
Fetal acoustic stimulator function, which can easily and safely wake up the sleeping fetus when monitoring
A standard patient event marker and a clinical event marking button to separately mark clinical events.
Many alarm functions are included: The monitoring time over alarm, no paper alarm.
Optionals
Twins monitoring
Maternal SpO2, NIBP, PR, ECG, TEMP, RESP
Specification
Alarm Range:
High limit: 160,170,180,190 bpm
Low limit: 90,100,110,120 bpm
Maximum audio output power : 1.5 Watt
Fetal Heart Rate:
Transducer: Multi-crystals, pulsed doppler , high sensitive
Strength: <5mW/cm2
Working frequency: 1.0MHz
Signal processing: special DSP system and modern recognization.
Measurement range: 30~210 bpm
Toco: Measurement range: 0~100 units
Resolution: 1
Fetal Movement: Button Hand Count ( Automatic cumulative number of movements
Pregnant HR Measure: Measure scope: 30bpm~240bpm. Measure accuracy: ±2 bpm
Maternal SpO2 measure: Measure scope : 70%~99%. Measure accuracy: ±3%
NIBP measure:
a) NIBP-SYS (6.7~32.0Kpa) (50~240mmHg)
b) NIBP-DIA (3.4~26.6Kpa) (25~200mmHg)
c) NIBP-MEAN (2.0~24.0ka (15~180mmHg)
NIBP Accuracy: ±1.1kPa (±8mmHg) or ±5% of the results, take the bigger one.
Maximum Mean error: ±5mmHg
Pulse Rate Accuracy: Maximum Mean error: ±2bpm
Measure accuracy: ±2 bpm or ±5% of the results, take the bigger one.
Maximum Standard deviation 8mmHg
Measure mode: Auto, Manual
Power: a.c.100-240V,50/60Hz or 8.4 Li-LON
Power Consumption: < 20W
Working Environment: Temperature: 5~40°C. Relative humidity: 10~80%
Dimension: 295W×240D×73H(mm)
Net weight: 1.75kg
Picture for HC-C008 Hot Sale 12.1 inch CTG Fetal Doppler Monitor/ Doppler fetal monitor:
Packaging & Shipping
Company Information
Our Services
Contact
FAQ
1. How to place order of HC-C008 Hot Sale 12.1 inch CTG Fetal Doppler Monitor/ Doppler fetal monitor?
A: Firstly we confirm product details and then send the Proforma Invoice,
You make payment to us through Trade Assurance or T/T, Western Union or MoneyGram,
after we confirm your payment then ship the product to you once finished production.
2. For HC-C008 Hot Sale 12.1 inch CTG Fetal Doppler Monitor/ Doppler fetal monitor product, What’s the minimum order quantity (MOQ)?
A: For disposable material,We have our own MOQ,For our HC-C008 Hot Sale 12.1 inch CTG Fetal Doppler Monitor/ Doppler fetal monitor, our MOQ:1pc,
3. What is your warranty?
A: For most products the warranty is for 12 months, some products we provide 18 months warranty.
For HC-C008 Hot Sale 12.1 inch CTG Fetal Doppler Monitor/ Doppler fetal monitor , we provide 12 months warranty.
4. What’s your delivery time?
A: Generally it is 5 working days if goods in stock. within 10 working days if the goods need production,
And also the delivery time depands on quantity. For HC-C008 Hot Sale 12.1 inch CTG Fetal Doppler Monitor/ Doppler fetal monitor, the delivery time is 10 working days .
5. How to ship the product?
A: The shipping way normally depand on your quantity,total CBM and weight.
We have our own shipping company to provide best shipping cost and efficient way.

---
