Basic Info.
Application
Double Beam Crane, Gantry Crane, Bridge Crane, Tower Crane, Single Grinder Crane, Lifting Platform, Small Crane
Maximum Lifting Height
2.8m
Product Name
Hh-V3 Handheld Workstation Intelligent Hoist
Lifting Speed(M/Min)
0-18
Vertical Maximum Stroke(M)
2.8(Customizable)
Control Mode
Handheld Comntinuously/Variable Transmission Handl
Power Supply
Standard 380V(Optional 220V)
Working Level of Theorganization
3m/M6
After Warranty Service
Video Technical Support
Core Components
Motor, Gear
Marketing Type
Marketing Type
Transport Package
Standard Export Packing
Production Capacity
5000sets Per Month
Product Description
Product Description
HH-V3 Series Handheld Workstation Intelligent Hoist
1.The handle adopts ergonomic principles, providing a comfort-able grip. It has dual control paddles, allowing for easy control of material lifting and
lowering with just one hand. Both hands can switch freely and be controlled alternately.
2.Continuously variable speed can achieve millimeter level movement, not only achieving more precise positioning, but also smoother operation,
lifting, and landing, fully leveraging the fast, accurate, and stable characteristics of intelligent elevators.
3.High cost-effectiveness, suitable for lifting various workstations. Not only does it reduce labor intensity, but it also improves the level of intelligent
equipment to ensure the fast-paced operation of automation work.
Product Details
Product Advantages
Product Parameters
Maximum Load(kg)
| 125
| 250
| 500
|
Lifting Speed(m/min)
| 0-18
| 0-15
| 0-12
|
Rated Power(kw)
| 0.75
| 0.75
| 1.1
|
Vertical Maximum Stroke(m)
| 2.8(Customizable)
|
Control Mode
| Coaxial sliding handle
|
Deadweight(kg)
| 23
| 23
| 32
|
Power Supply
| Standard 380V(Optional 220V)
|
Working Level of the Organization
| M5
|
Working Temperature
| -10-55
|
Product Application
Product Display
Packaging & Shipping
