| Model 9.9/15/18/20HP |
| Demension Overall Length: 570mm(22.4in) Overall Width: 290mm(11.4in) Overall Height S: 1060mm(41.7in) Overall Height L: 1170mm(46in) |
| Weight S: 38Kg(83.7lbs) L: 40Kg(88.1lbs) |
| Full Throttle Operating 5000-6000r/m |
| Maximum Output 7.3-11kw/15hp |
| Idling Speed 1050±50r/m |
| Displacement 246cc |
| Bore X Stroke 56X50mm(2.2X1.96in) |
| Ignition System CDI |
| Spark Plug NGKBR7HS-10 |
| Spark Plug Gap 0.9-1 .Omm |
| Control System Tiller Handle |
| Starting System Manual |
| Starting Carburation System Choke Valve |
| Gear Position Forward-Neutral-Reverse |
| Gear Ratio 2.08(27:13) |
| Trim And Tilt System Manual Tilt |
| Recommended Fuel WUnlead Gasoline |
| Recommended Engine Oil 2-Stroke Outboard Motor Oil |
| Blended Fuel Oil Ratio 50:1 |
| Gea OiL 0.250L |
| Fuel Tank (Opacity) 24L |
| Torque 20N.m/2500rpm |
| propeller 9Z.X9-J1 |
| Fuel Consumption 9L/h |
| Packing Size 143.5*72*45CM |
