| US$8,600.00-9,400.00 | 1 set (MOQ) |
| Engine Model | Kubota D722 10.4KW/2500rpm |
| Max. Turque | 45N.m/2500RPM |
| Type | In-line, water cooled, 4 stroke, Mechanical pump, normally aspirated |
| Displacement | 0.719 |
| No. of cylinder | 3 |
| Swing Speed | r/min | 12-13 |
| Traveling Speed(high/low) | km/H | 2.1/3.2km/h |
| Grade ability | ° | 58% |
| Max. Bucket Digging Force | kN | 9 |
| Arm Digging Force | kN | 5.5 |
| Ground Pressure | Kpa | 23 |
| Hydraulic system pressure | Mpa | 20 |
| Machine Weight | KG | 1400 |
| Fuel Tank capacity | L | 14.5 |
| Hydraulic Tank capacity | L | 14.5 |
| Engine oil capacity | L | 3.2 |
| Overall Length | mm | 3329 |
| Overall Width | mm | 990 |
| Overall Height | mm | 2267 |
| Mini Ground clearance | mm | 153 |
| Track width | mm | 200 |
| Axle base(Track length on ground) | mm | 1190 |
| Track Gauge | Mm | 790(1100) |
| Swing radius at tail | Mm | 655 |
| Swing radius at front | Mm | 1812 |
| Height of blade | Mm | 210 |
| Max.Dozer blade cutting | Mm | 229 |
| Max.Dozer blade lifting | mm | 236 |
| Bucket Capacity | m3 | 0.025 |
| Max. Digging Radius | mm | 3529 |
| Max. Digging Depth | mm | 2017 |
| Max. Digging Height | mm | 2955 |
| Max. Dumping Height | mm | 2077 |
| Max. vertical digging depth | mm | 1610 |
