| PICTURE |
|
|
| SIGNAL FORMAT CAPABILITY |
|
| Category | D-LED |
|
| Component Video Format | 480i,480p,576i,576p,720p,1080i,1080p |
| Naturalight Technology | / |
|
| CVBS Video Format | PAL/NTSC/SECAM |
| Dynamic Contrast | Yes |
|
| HDMI Video Format | 480i,480p,576i,576p,720p,1080i,1080p |
| Color Temperature | Warm / Normal / Cold |
|
| PC Compatibility | up to 2160P@60Hz |
| Backlight Adjustable | Yes |
|
| TERMINALS |
|
| Scale Mode | Zoom+8,Zoom-1/4 |
|
| YPBPR (MINI) Input | / |
| Picture Effect | Standard, Dynamic,mild,user |
|
| Stereo Audio Input for YPBPR | 1 |
| Film Mode (3:2 pull down) | AUTO |
|
| AV Input (Composite) | 1 |
| VGA Dot to Dot Display | Yes (Natural) |
|
| VGA(PC) Input | 1 |
| Picture Enhancement |
|
|
| Audio Input for VGA(PC) | 1 |
| Comb Filter | 3D |
|
| HDMI | 3 |
| Adaptive Deinterlacing | 3D |
|
| RF Input | 1 |
| Blue Stretch | Yes |
|
| SCART | / |
| Black Stretch | Yes |
|
| CI | / |
| DLTI | Yes |
|
| CVBS Output | 1 RCA---BELOW |
| DCTI | Yes |
|
| USB2.0 | 2 Standard USB--SIDE |
| Dynamic Skin Correction | Yes |
|
| Headphone Output | 1 Miniature Phone Jack---SIDE |
|
|
|
| BASIC INFO. |
|
| PANEL SPECIFICATION |
|
|
| TV System | DVB-T2 |
| Back light Unit | LED |
|
| AV System | PAL,NTSC,SECAM |
| Panel supplier | BOE/CSOT/LG/AUO（optional） |
|
| Channels | / |
| Aspect Ratio | 16:9 |
|
| MAIN board | 3 in 1 board |
| Panel Size (inch) | 43" |
|
| DVD | NO |
| Display Resolution | 3840*2160 |
|
| Certification | / |
| Brightness (cd/m2) | 220 ±10% cd/m2 |
|
| Power Supply | 100-240VAC 50/60HZ |
| Contrast Ratio | 1000:1 |
|
| Power Consumption-TV on | ≤75W |
| Response Time | 8ms |
|
| Power Consumption-Standby | ≤0.5W |
| Viewing Angle (H/V) | 178°(H) X 178°(V) |
|
| Power Plug | / |
| Life Time | 30000 hrs |
|
| Default Color of Front Cabinet | Black |
| Color | 16.7M |
|
| Keyboard Position | BACK |
| Toughened glass | Yes |
|
| Base Stand Detachable | Yes |
| SOUND |
|
|
| PACKAGE INFO. |
|
| Speakers | Integrated speakers 8Ω 10W |
|
| Unpackaged Dimension for Main Body (L*D*H) (mm) |
|
| Audio Power Output | 2×8W |
|
| With Base Stand (mm) | 973*565*81 |
| Audio Power Output Effect | 2×8W Maximum Sound Pressure Level |
|
| Without Base Stand (mm) | 973*565*58 |
| Woofer Power Output | -- |
|
| Packaged Dimension (L*D*H) |
|
| Smart Volume | Yes |
|
| Main Body (mm) | 1027*630*113 |
| Sound Effect | Standard, Movie, Music,user |
|
| Speaker Box | NA |
| Sound Control | Balance, Bass,Treble |
|
| Base Stand | Packaged with Main Body |
|
|
|
| Net Weight (Kg) |
|
| FUNCTION |
|
|
| Gross Weight (Kg) |
|
| OSD Language | English/French/German/Italian/Spanish/Portuguese (Optional) |
|
| Container Loading |
|
| OSD Features | / |
|
| 20 feet | 414 |
| Source in OSD | / |
|
| 40 feet | 750 |
| Teletex | / |
|
| 40 feet high | 960 |
| Clock/Sleep Timers | Yes |
|
| ACCESSORIES |
|
| DNR（Dynamic Noise Reduction） | Yes(off、low、Middle,High) |
|
| Operation Manual | English(Default) |
| Hotel Menu | Off(Optional) |
|
| Remote Control | For TV control |
| USB Connection | Video:Suppor MPEG,AVI,MP4,MKV,RMVB etc |
|
| Base Stand | Integrated Packaging |
|
|
| Speaker Box | Integrated |
| Photo: Support JPEG、BMP |
|
| Wall Mount |
|
| Music: support MP3,AAC,wma |
|
| Others | AC Power cord |
|
|
|
| Andriod | andriod11.0 system,1G DDr,4G eMMc |
