Basic Info.
Type
Tool Milling Machine
Milling Cutter Type
Customized
Milling Cutter Structure
Customized
Controlling Mode
Artificial
Certification
GS, CE, RoHS, ISO 9001
Name
High Precision Horizontal Turret Milling Machine
Spindle Motor Power
3.7kw 5HP
Transport Package
Wooden Pallet
Production Capacity
100 Sets Per Month
Packaging & Delivery
Package Size
157.00cm * 165.00cm * 208.00cm
Package Gross Weight
1630.000kg
Product Description
Hot-selling High Precision Horizontal Turret Milling Machine X6330
| Model | Unit | X6330 | X6330A |
| Table size | mm | 305×1370(12"×54") 305×1500(12"×58") |
| T slot No.and size | | 3 × 16 |
| Long travel | mm | 870(1000) |
| Cross travel | mm | 360 |
| Vertical travel | mm | 380 |
| Distance from horizontal spindle to table | mm | 0-350 |
| Ram travel | mm | 500 |
| Spindle taper | | (standard):ISO40 |
| Spindle travel | mm | 127 |
| Spindle speed | rpm | (standard):(shiftgrade) 50HZ65-4500 60HZ:80-5440 |
| (optional):(variable)65-3750 |
| Auto.quill feed | mm/rev | (threesteps):0.04(0.0015")/0.08(0.003")/0.15(0.006") |
| Spindle motor power | kw | 3.7 kw/5HP |
| Head swivel | ° | 90° |
| Head tilting | ° | 45° | FIX |
| Dimension of package | mm | One miller per case 1566×1650×2080 |
| Two miller per case 1720×1800×2175 |
| G.W/set | kg | 1630 | 1650 |
Features:
1. High rigidity and quality casting iron, and saddle guide-way is coated by TF-material.
2. 16 steps speed milling head made in Taiwan, variable speed milling head and inverter milling head can be equipped as optional accessories.
3. X/Y/Z-axis screw are made in Taiwan with good smooth and reliable features.
4.Table surface is treated specially to harden HRC45-55.
5. X/Y/Z-axis guide way surface are treated specially to harden HRC45-55.
Standard accessories:
ISO40 spindle taper, 3.7kw / 5HP Taiwan milling head,
16 steps spindle speed (50HZ): 65-4500rpm , (60HZ): 80-5440rpm
Hardened worktable and guide, Lead screw from Taiwan, Finely ground central T-slot,
guide way with Turcite B cover, spindle bearing with P4 class ,Hand oil pump,
Work light, Draw bar,Electric cabinet, Tool and tool box,
>>
