| Type & Size | MXL,XL,L,H,XH,XXH,T2.5,T5,T10,T20,AT5,AT10,AT20,HTD2M- 20M,STPD/STS2M-14M,RPP/HPPD2M-14M; As per the demands of customers |
| Material | PU Rubber, Steel reinforced, Fabric, Kevlar cord. |
| Mechanical properties | Dimensional stability; Strong low; Low noise; High wear resistance; No need to maintain; High elastic |
| Working temperature | +30°C to +80°C, Instant high temperature: +110°C |
| Working Pressure | ≤32Mpa Bud -Shape Ring≤50Mpa |
| Working Medium | Hydraulic Oil |
| Characteristics | Aging proof, waterproof, prevent UVA, Ozone-resistant, highly resistant to oil, acid and alkali corrosion resistance |
| Processing | punch/ slot / pattern / block / guide bar / profile |
| Colors | White,black,Red,Various |
| Application | Stone, ceramic,glass,electronics,aluminum, textile, logistics,printing,packaging,paper products processing industries etc. |
| Certification | ISO9001:2000 |
| Type | Pitch (mm) | Tooth Height (mm) | Belt Thickness(mm) |
| H | 12.7 | 2.29 | 4.3 |
| L | 9.525 | 1.9 | 3.6 |
| XL, DXL | 5.08 | 1.27 | 2.3 |
| MXL, DMXL | 2.032 | 0.51 | 1.2 |
| S2M | 2.0 | 0.76 | 1.36 |
| S3M, D3M | 3 | 1.91 | 3.4 |
| S5M | 5 | 1.91 | 3.4 |
| 3M | 3 | 1.13 | 22 |
| 5M, D5M | 5 | 2.1 | 3.6 |
| 8M, D8M | 8 | 3.4 | 5.6 |
| RPP 14M | 14 | 6 | 10 |
| T2.5 | 2.5 | 0.7 | 1.3 |
| T5, DT5 | 5 | 1.27 | 2.3 |
| T10, DT10 | 10 | 2.5 | 4.5 |
| AT5 | 5 | 1.2 | 2.7 |
| AT10, DAT10 | 10 | 2.5 | 4.5 |
| AT20 | 20 | 5 | 8 |
