| Negotiable | 1 Piece (MOQ) |
| 430 | 550 | 650 | 850 | 1160 | |
| X travel (mm) | 430 | 550 | 650 | 800 | 1100 |
| Y travel (mm) | 300 | 350 | 400 | 500 | 600 |
| Z travel (mm) | 450 | 500 | 500 | 500 | 750 |
| spindle nose to table (mm) | 100-550 | 100-600 | 120-620 | 120-620 | 150-900 |
| spindle center to column (mm) | 383 | 419 | 481 | 581 | 659 |
| X rapid feed (m/min) | 20 | 20 | 20 | 20 | 36 |
| Y rapid feed (m/min) | 20 | 20 | 20 | 20 | 36 |
| Z rapid feed (m/min) | 20 | 20 | 20 | 20 | 24 |
| cutting feed (m/min) | 1-10 | 1-10 | 1-10 | 1-10 | 1-10 |
| torque(X/Y/Z) (N·m) | 5/5/5 | 7/7/7 | 7/7/10 | 12/12/20 | 20/20/20 |
| table size (mm) | 700×300 | 700×350 | 800×400 | 1000×500 | 1200×600 |
| table max load (kgs) | 200 | 300 | 350 | 500 | 700 |
| table surface to ground (mm) | 760 | 820 | 840 | 840 | 950 |
| T slot (mm) | 3×16×110 | 3×18×105 | 3×18×125 | 3×18×150 | 5×18×100 |
| spindle type | Belt | ||||
| spindle speed (rpm) | 8000 | ||||
| spindle taper | BT30 | BT40 | |||
| main motor (kw) | 3.7 | 5.5 | 5.5 | 7.5 | 11 |
| Accuracy(JIS)(mm) | ±0.005/300 | ||||
| repeatibility (JIS)(mm) | ±0.003 | ||||
| machine weight (kgs) | 2000 | 2500 | 2900 | 4200 | 7000 |
| machine size (mm) | 1800*1700* 2100 | 2000*1900* 2300 | 2200*1950* 2300 | 2500*2200* 2500 | 3200*2500* 2900 |
| Standard accessory | Optional accessory |
| Fanuc-0i-mate-MF | Mitsubishi M70/GSK218M/ Stntec controller |
| full enclosure machine guard | Arm type tool changer |
| Funnel type ATC | chip cart |
| automatic central lubrication system with alarm | 4th axis |
| Z axis counter-balance weight | Metrol tool setters |
| spindle cooling unit | transformer to suit local power supply |
| spindle side air blow nozzle&coolant nozzle | screw type chip conveyor |
| machine window with safety glasses | |
| rigid tapping | |
| auto power off | |
| 3 colours warning lamp | |
| work lamp | |
| leveling pads&bolts | |
| operation manuals | |
| tool holder and pull stud |
