Basic Info.
Usage
Special Excavator, Earthmoving Excavator
Transmission
Hydraulic Transmission
Drive Type
Electric Drive
Bucket Capacity
1.0~1.5m³
Certification
CE, ISO9001: 2000
Starting Motor
24 V, 4.5 Kw
Ground Clearance of Counterweight
1060mm
Track Shoe Width
Triple Grouser 600mm
Main Pump
Variable Displacement Tandem-Axis Piston Pumps
Travel Motor
Two Speed Axial Pistons Motor with Brake Valve and
Specification
9600*3000*3000mm
Production Capacity
15 Units/Month
Packaging & Delivery
Package Size
9600.00cm * 3000.00cm * 3000.00cm
Package Gross Weight
22.000kg
Product Description
Company Profile
If interested, leave message to Willow Shen.
Product Description
China shantui newpower 22 ton cheap excavator SE220 model from
Main Features:
The medium-sized workhorse in Shantui's lineup of excavators, the SE220 comes standard with imported Kawasaki hydraulics and Korean-made cylinders. It has a state-of-the-art multifunctional monitor, four working modes and either electronic or manual throttle controls. It sports an imported Cum-mins B series engine.
The boom confluence and diffluence combine for superior swing performance, making digging more efficient.
Product Parameters
Technical parameters:
item
| value
|
Bucket capacity
| 1.2 m³
|
Hydraulic Cylinder Brand
| Famous Brand
|
Engine Brand
| Famous Brand
|
Place of Origin
| China
|
Machine Weight
| 22000kg
|
Warranty
| 1 Year
|
Hydraulic Pump Brand
| Famous Brand
|
Hydraulic Valve Brand
| Famous Brand
|
UNIQUE SELLING POINT
| High operating efficiency
|
Power
| 148hp/2000rpm
|
Core Components
| PLC, Pressure vessel, Other, Gear, Engine, motor, Pump, Bearing, Gearbox
|
Brand Name
| HL
|
Moving Type
| Crawler Excavator
|
Maximum Digging Height
| 9600 mm
|
Maximum Digging Depth
| 6730 mm
|
Max Digging Radius
| 9980 mm
|
Make
| HL
|
Rated Speed
| 5.7 km/h
|
Machinery Test Report
| Provided
|
Video outgoing-inspection
| Provided
|
Product name
| Crawler Excavator
|
Keywords
| Heavy Equipment
|
Model
| HX220HD
|
Type
| General-purpose Excavator
|
Feature
| Powerful Digger
|
Brand
| HL
|
Engine
| HM5.9
|
Origin
| China Mainland
|
Color
| Customers Requirements
|
MOQ
| 1 UNIT
|
