Dawson Aluminum Lever Chain Hoist, Manual Lever Block

Product Description

Dawson Aluminum Lever Chain Hoist, Manual Lever Block
Introducing the international high-end technology.
Safety factor : four times.
Small and light, easy to carry.
High work effiency and light hand force.
Easy to maintain and.
The hoist body uses the high strength alloy steel and in sealed gear cover, to assure the safety.
Brake system uses the two pawls, with higher safety and stability.
The handle lever is designed in disconnect-type and easy to carry. When overload, the handle will be deformed to remind the user.
With brake clutch device, the chan can be adjusted and rotated when non-load. It can help to adjust the hook position and improve the work efficiency.

Model		DS-AL-D3	DS-AL-D6	DS-AL-D9	DS-AL-D12
Capacity	t	3	6	9	12
Standard	m	1.5	1.5	1.5	1.5
Running test	kN	36.8	73.5	110	147
Effort required to lift max load	N	240	260	280	280
Load chain diameter	mm	8	8	8	8
Falls		1	2	3	4
Min distance between hooks(H)	mm	445	575	770	720
Dimensions(mm)	A	205	205	205	205
	B	125	125	125	125
	C	149	195	253	318
	D	460	460	460	460
	E	31	39	45	53
	φ	45	55	65	70
N.W.	kg	13.2	20.5	35.5	36.5
Loading Chain Weight/Meter	kg	1.42	2.84	4.26	5.68

Products Show
Other Related Products Show:
Company Profile
DAWSON GROUP LTD. is an ISO 9001 certified firm, specializes in the field of Lifting & Hoisting Equipments, Lashing Equipments, Material Handling Equipments, Rigging & Marine hardware, Wire Ropes, Chains, Polyester Slings, Ratchet Straps, Auto parts, Tools and other products.
DAWSON puts customers' requirements firstly,provides timely and effective one-stop solutions. Standardized and efficient operating procedures ensure the goods are delivered accurately and quickly to all parts of the world. We are pleased to establish a strategic partnership with you.
Certificate
The Qualification-Certificate of DAWSON GROUP LTD. and correlative productsPolyester webbing slings, round slings, ratchet tie downs, anchor, anchor
chains, marine rigging hardware....
Most of our products are CE, TUV & GS certified. The marine hardwares we approved CCS,ABS, LR, DNV, BV, GL, KR, KN, and RINA certificates.
Testing
Package & Factory
Other Products

FAQ
Q1:Can I expect quality products?
Yes. All our activities are accredited to ISO 9001 and based on delivering the highest quality possible, both in products and services, ensuring long-term benefits and optimum performance. Also we got the below certifications: CE GS SUV, LR ABS(anchors and anchor chains). Our rigging hardware is manufactured under exceptional quality control and strictly adheres to the US,DIN,JIS,BS and AS standards.
Q2:Can I get a (free) sample?
Free cost if the quantity is small or value is not too high with the express charge covered by the buyers. And for some certain items after receiving the first formal order, we deduct the sample cost from it. Everything can be negotiated for a sincere cooperation.
Q3:What's your payment terms?
T/T in U.S.dollars or EUR. when the total price is higher than US$10,000.00, it is 30%T/T in adv, balance payment against the copy of B/L; when the total price is lower than US$10,000.00,100%T/T in adv.
Q4:What's your lead/shipment time? And how soon can I receive my goods?
For all of our products are manufactured according customers' order, the lead time is usually within 15-40 days after reception of your deposit. Usually, from China to Europe, it will take about 22 days; to west of American, 20 days. Usually shipped by sea, or air, DHL, UPS or Fedex, TNT.
Q5:What is your Minimum Order Quantity(MOQ)?
Different products with different limits. Please contact us to confirm. Generally, we are not doing retailing for we are supplying our quality products and competitive price to our distributors.
Q6:Who and where are you?
We are factory, seller, inspector, QA, QC, purchaser, service… We are in Qingdao City, Shandong Province, China, the base of China Rigging Center. Our min-metal forging and Grade 80 components factory located in Shandong Province with a long history of more than 50 years in these fields.
Q7:What products can you supply?
Rigging,marine,lifting,lashing,sling,mining,fishing,trucking,transporting,safety concerned products, and full set of rigging accessories, including trade service in the fields such as: material handling, load restraint, cargo control, anchor shackle, chain shackle, wire rope product, chain product, lifting component, chain sling, webbing sling, round sling, cargo tie down, ratchet straps and hooks…
Q8:How to order the target products?
Send us inquiry with detailed item description or with item number provided on MADE-IN-CHINA or our official website. Tell us the quantity, size, and packing demand you want. If possible please attach reference pictures to avoid misunderstanding.

---
